Zebra DS9300 Series DS9308 / Standard Range (SR) / USB Kit / barcode scanner / desktop / 2D imager / 3050 mm / sec / decoded / USB | DS9308-SR4U2100AZE
Please sign in so that we can notify you about a reply
Product Features
- Scan it all
With an fast microprocessor, high-resolution megapixel sensor and exclusive imaging technology, the DS9300 Series instantly captures barcodes in virtually any condition, on any media. - Innovative-driven design
With a near-zero footprint, there's always room for the DS9300 Series, no matter how space-constrained your counters may be. Recessed LEDs are virtually invisible and automatically dim when not in use - reducing eye annoyance. The scanner's ratcheting base offers four positions for convenient scanning, and its frictionless design won't wear out. - Maximum durability and reliability
Drops, dust and spills are no problem for the DS9300 Series. It's built to handle drops to concrete and tumbles. And thanks to IP52 sealing and a opto-mechanical layout that includes a concealed beeper hole with elevated circuitry and cable connector, even the base is spill proof.
Special Features
- Scan it all
- Innovative-driven design
- Maximum durability and reliability
Product Specification
| Type | Barcode scanner - desktop |
| Colour | Midnight black |
| Localisation | EMEA |
| Barcode | Barcode |
| Interface Type | USB |
| Minimum Bar Width | 3 mil |
| Scan Element Type | 2D imager - Red LED |
| Sensor Resolution | 1280 x 800 |
| Light Source Wave Length | 617 nm |
| Scan Mode | Single-pass |
| Scan Speed | 3050 mm / sec |
| Max Working Distance | 27.9 cm |
| Skew (Degrees) | 60 |
| Pitch (Degrees) | 60 |
| Print Contrast Signal (PCS) | 15% |
| Decode Capability | Code 93, Matrix 2 of 5, Code 39, UCC/EAN-128, ISBT 128, NW-7, IATA, ISBN, coupon code, GS1 DataBar, MaxiCode, Aztec code, Bookland, Code 39 Full ASCII, EAN/JAN-8, EAN/JAN-13, UPC-A, UPC-E, Discrete 2 of 5, MicroPDF417, Italy Pharmacode, Codabar, Code 128, Code 11, UPC, Interleaved 2 of 5, Postnet, PDF417, MSI-Plessey, ITF, PLANET, TLC39, Australian Post, Japanese Post, Kix (Netherlands) Post, IATA 2 of 5, UPC-E1, UPC-A/EAN-13 with Extended Coupon Code, EAN-UCC Composite, MacroPDF417, ISSN, Code 128 Full ASCII, Code 39 Trioptic, UK Post, Royal Mail, 4-State postal code, CC-B, GS1 DataBar Omnidirectional, GS1 DataBar Expanded Stacked |
| TTL Decoding | Decoded |
| Connectivity Technology | Wired |
| OK Notification | Beeper, LED indicator |
| Features | ESD (electrostatic discharge) safe, deactivation of EAS tag, standard range scanning |
| Expansion / Connectivity | Expansion / Connectivity |
| Interfaces | 1 x USB |
| Miscellaneous | Miscellaneous |
| Cables Included | 1 x USB cable - external |
| Compliant Standards | EN 61000-4-2, IP52, EN 50581:2012, EN 62471:2008, EN 61000-3-3:2013, EN 55024:2010, FCC CFR47 Part 15 B Class B, EN 55024:2010+A1:2015, EN 62368-1, IEC 62368-1, ICES-003 issue 6 Class B, EN 55032:2012+AC:2013 Class B, EN 61000-3-2:2014 Class A, IEC 62471-1:2006, EN 55032:2015+AC:2016 Class B, EN 55035:2017 |
| Power | Power |
| Power Device | Power adapter |
| Electric Current Required | 135 mA (standby), 335 mA (typical) |
| Dimensions & Weight | Dimensions & Weight |
| Width | 8.6 cm |
| Depth | 8.3 cm |
| Height | 14.5 cm |
| Weight | 318 g |
| Manufacturer Warranty | Manufacturer Warranty |
| Service & Support | Limited warranty - 3 years |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 50 °C |
| Humidity Range Operating | 5 - 95% (non-condensing) |
| Drop Specification | 1.5 m to concrete |
Features - Zebra Technologies - DS9308-SR4U2100AZE
More Details
Product Code
07:127892
Manufacturer
Zebra Technologies
