Edimax ES-1008P - V2 - switch - 8 x 10/100 (PoE+) - desktop - PoE+ (130 W) | ES-1008P V2
Please sign in so that we can notify you about a reply
Product Features
- Complies with IEEE 802.3at Power over Ethernet (PoE)
The ES-1008P features 8 IEEE 802.3at Power over Ethernet (PoE) ports, which supply up to 30 watts of power per port. The ES-1008P also features PoE detection, to verify whether the connected device is IEEE 802.3at compliant; if it is not a PoE device, only data will be sent through the LAN cable. The ES-1008P can connect with a variety of PoE products, including access points, IP cameras and IP phones. - No special networking cable required
The standard Cat-5 Ethernet cable is used to link the ES-1008P and the powered devices. This Ethernet cable can transmit both data and power. No separate power cable is needed for the powered devices, thus reducing installation time and costs.
Special Fetures
- Complies with IEEE 802.3, 802.3u, 802.3x, 802.3af, and 802.3at standards
- Automatically detects powered devices (PD) and power consumption levels
- Supports auto fault detection
- Supports IEEE 802.3az Energy Efficient Ethernet
Product Specification
| Device Type | Switch - 8 ports |
| Enclosure Type | Desktop |
| Subtype | Fast Ethernet |
| Ports | 8 x 10/100 (PoE+) |
| Power Over Ethernet (PoE) | PoE+ |
| PoE Budget | 130 W |
| Performance | Switching capacity: 1.6 Gbps |
| MAC Address Table Size | 1K entries |
| Features | VLAN support, store and forward, Quality of Service (QoS), fanless, 128KB packet buffer |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3at, IEEE 802.3az |
| Status Indicators | Power, PoE, link/activity |
| Expansion / Connectivity | |
| Interfaces | 8 x 100Base-TX RJ-45 PoE+ - 30 W |
| Power | |
| Power Device | Internal power supply |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Power Consumption Operational | 5 Watt |
| Miscellaneous | |
| Compliant Standards | FCC, LVD |
| Dimensions & Weight | |
| Width | 26.51 cm |
| Depth | 18.37 cm |
| Height | 4.4 cm |
| Weight | 1.605 kg |
| Environmental Parameters | |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 40 °C |
| Humidity Range Operating | 10 - 90% (non-condensing) |
| Min Storage Temperature | -40 °C |
| Max Storage Temperature | 70 °C |
| Humidity Range Storage | 5 - 90% (non-condensing) |
Features - Edimax - ES-1008P V2
General
8-Port
More Details
Product Code
04:230881
EAN Code
4717964701558
Manufacturer
Edimax
