Elo 1723L / LED monitor / 17" / touchscreen / 1280 x 1024 @ 75 Hz / 250 cd/m² / 800:1 / 30 ms / DVI, VGA / speakers / white | E016808
Please sign in so that we can notify you about a reply
Special Features
- Integrated peripheral options include a Magnetic Stripe Reader (MSR), RFID reader and webcam
- Integrated cable management
- iTouch Plus surface acoustic wave (SAW) touchscreen couples zero-bezel design with multi-touch functionality
- Dual position stand - single hinge with high/low settings and tilt functionality
- Desktop, wall or VESA mounting
- Internal speakers
Product Specification
| Display Type | LED-backlit LCD monitor / TFT active matrix |
| Diagonal Size | 17" |
| Built-in Devices | USB Hub |
| Aspect Ratio | 5:4 |
| Native Resolution | 1280 x 1024 at 75 Hz |
| Brightness | 250 cd/m² |
| Brightness w/touchscreen | 215 cd/m² |
| Contrast Ratio | 800:1 |
| Colour Support | 16.7 million colours |
| Response Time | 30 ms |
| Vertical Refresh Rate | 56 - 75 Hz |
| Horizontal Refresh Rate | 31 - 80 KHz |
| Horizontal Viewing Angle | 170 |
| Vertical Viewing Angle | 160 |
| Backlight Technology | LED backlight |
| Controls & Adjustments | Mute, volume, brightness, contrast, H/V position, sharpness, colour temperature, phase, clock, aspect control |
| OSD Languages | Chinese (traditional), Chinese (simplified), English, German, French, Italian, Spanish, Japanese |
| Features | Anti-glare, IntelliTouch Pro |
| Colour | White |
| Dimensions (WxDxH) | 39.19 cm x 20.94 cm x 36.07 cm - with stand |
| Weight | 5.21 kg |
| Audio | Audio |
| Type | Speakers - stereo |
| Output Power / Channel | 2 Watt |
| Input | Input |
| Type | Touch-screen - touchscreen |
| Movement Detection Technology | Projected capacitive |
| Connectivity | Connectivity |
| Interfaces | VGA ¦ DVI-D ¦ 2 x USB (Type A) ¦ USB (Type B) ¦ USB upstream (Type B) |
| Mechanical | Mechanical |
| Display Position Adjustments | Height, tilt |
| Tilt Angle | -5/+90 |
| VESA Mounting Interface | 75 x 75 mm |
| Miscellaneous | Miscellaneous |
| Features | Security lock slot (cable lock sold separately) |
| Included Accessories | Cable management clip |
| Cables Included | 1 x VGA cable - VGA to VGA ¦ 1 x DVI cable - DVI-D to DVI-D ¦ 1 x audio cable ¦ 1 x USB cable - USB Type A to B |
| MTBF | 50,000 hour(s) |
| Compliant Standards | Plug and Play, UL, VCCI, C-Tick, BSMI, cUL, VESA DPMS, CB, CCC, IC, FCC, RoHS, KCC, WEEE, E-Standby, China RoHS, CoC |
| Power | Power |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Power Consumption Operational | 22 Watt |
| Power Consumption (Typical) | 22 Watt |
| Power Consumption Sleep | 2 Watt |
| Dimensions & Weight | Dimensions & Weight |
| Dimensions & Weight Details | Without stand - width: 39.19 cm - depth: 4.95 cm - height: 32.72 cm - weight: 3.56 kg ¦ With stand - width: 39.19 cm - depth: 20.94 cm - height: 36.07 cm - weight: 5.21 kg |
| Manufacturer Warranty | Manufacturer Warranty |
| Service & Support | Limited warranty - 3 years |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 40 °C |
| Humidity Range Operating | 20 - 80% (non-condensing) |
Features - Elo - E016808
Resolution
1280 x 1024
More Details
Product Code
0V00257
EAN Code
0834619007361
Manufacturer
Elo
