Epson WorkForce DS-730N / Document scanner / Contact Image Sensor (CIS) / Duplex / A4 / Legal / 600 dpi x 600 dpi / ADF (100 sheets) / USB 2.0, Gigabit LAN | B11B259401
Product Features
- Sharing made easy
With limited office space, reducing the number of dedicated devices is crucial. With an easy-to-use control panel with built-in 1.44" color LCD display, you can choose the correct job and send documents to the correct destination without delay, making digital files available across departments and other agencies. Scan to email, folder, FTP, SFTP, cloud services or Microsoft applications at the touch of a button. - High performance
Thanks to a high-capacity 100-sheet ADF, user intervention is reduced, allowing you to capture high volumes of documents in one go. With double-sided scan speeds of up to 40 ppm/80 ipm, bulk jobs can be captured quickly and easily as a single file. - Intelligent features
Take control with a range of intelligent features, including ultra-sonic sensors and a paper protection function. Slow mode allows difficult media to be captured by reducing roller speed, without increasing file sizes. Double feed detection skip means difficult documents like envelopes and post-it notes can be processed rapidly. - Quick send buttons
Thanks to WebConfig, you can create job presets and assign them to one of three quick send buttons, without the need for a PC or server. Multiple email addresses can be assigned to a single job. Scan once and send to several different contacts. Up to 300 separate contacts can be saved.
Special Features
- Standalone network scanning: release the potential of a connected workplace
- File sharing: one-touch scan to different destinations
- Reliable paper handling: take control with ultra-sonic sensors and paper protection
- Speed with control: use slow mode or scan documents with speeds of up to 40 ppm (80 ipm)
- Built-in display: easy-to-use 1.44-inch color LCD
Product Specification
Type | Document scanner - desktop |
Interface Type | USB 2.0, Gigabit LAN |
Additional Functions | Scan to network share, scan to server, scan to FTP, scan to email |
Max Supported Document Size | Legal (216 x 356 mm)/A4 (210 x 297 mm) |
Scanner | Scanner |
Input Type | Colour |
Grayscale Depth | 10-bit grey |
Grayscale Depth (External) | 8-bit (256 grey levels) |
Colour Depth | 30-bit colour |
Colour Depth (External) | 24-bit (16.7 million colours) |
Optical Resolution | 600 dpi x 600 dpi |
Scan Mode | Single-pass |
Automatic Duplexing | Yes |
Scanning Sensor Type | Contact Image Sensor (CIS) |
Bulb / Light Source Type | LED |
Max Document Scan Speed B/W | 40 ppm |
Max Document Scan Speed Colour | 40 ppm |
Duty Cycle | 4500 scans per day |
Scanner Speed Details | 40 ppm - black & white - A4 - 300 dpi ¦ 80 ipm - duplex - black & white - A4 - 300 dpi ¦ 40 ppm - colour - A4 - 300 dpi ¦ 80 ipm - duplex - colour - A4 - 300 dpi ¦ 40 ppm - black & white - A4 - 200 dpi ¦ 80 ipm - duplex - black & white - A4 - 200 dpi ¦ 40 ppm - colour - A4 - 200 dpi ¦ 80 ipm - duplex - colour - A4 - 200 dpi |
Scanner Features | Barcode Detection, Text Enhancement, Punch Hole Removal, A3 stitching, 1.44" LCD screen, auto image rotation, Advanced Colour Dropout, edge fill |
Scan File Formats | JPEG, PNG, TIFF, PDF, Multi-TIFF, XLSX, PPTX, DOCX |
Compliant Standards | TWAIN, ISIS, WIA |
Media Handling | Media Handling |
Max Document Size | 215.9 mm x 6096 mm |
Supported Document Type | Plain paper |
Document Feeder Type | Automatic |
Document Storage Capacity | 100 sheets |
Expansion / Connectivity | Expansion / Connectivity |
Interfaces | USB 2.0 - Type B ¦ Gigabit LAN |
Miscellaneous | Miscellaneous |
Cables Included | 1 x USB cable |
Power | Power |
Power Device | External power adapter |
Voltage Required | AC 100 - 240 V (50 - 60 Hz) |
Power Consumption Operational (Standby) | 14 Watt |
Power Consumption Stand by | 5.9 Watt |
Power Consumption Sleep | 1.5 Watt |
Software / System Requirements | Software / System Requirements |
Software Included | EPSON Event Manager, EPSON Document Capture Pro, EPSON Document Capture Pro Server, EPSON Scan 2, Epson Device Admin |
OS Required | Microsoft Windows XP Professional x64 Edition, Microsoft Windows Server 2008 R2, Microsoft Windows Vista (32/64 bits), Apple MacOS X 10.6.x or later, Microsoft Windows Server 2008 (32/64-bits), Microsoft Windows Server 2003 (32/64-bits), Microsoft Windows Server 2012 x64 Edition, Microsoft Windows Server 2012 R2, Windows 10, Microsoft Windows 7 / 8 / 8.1 / 10 (32/64 bits) |
Dimensions & Weight | Dimensions & Weight |
Width | 29.6 cm |
Depth | 16.9 cm |
Height | 16.7 cm |
Weight | 3.6 kg |
Manufacturer Warranty | Manufacturer Warranty |
Service & Support | Limited warranty - 1 year - on-site |
Environmental Parameters | Environmental Parameters |
Min Operating Temperature | 5 °C |
Max Operating Temperature | 35 °C |
Humidity Range Operating | 15 - 85% (non-condensing) |
