equip Cat6A U/UTP Installation Cable, LSZH, 305m | 401496
401496
Find similar
Delivery
Payment options
Please sign in so that we can notify you about a reply
The equip® Installation Cable is made of preeminent materials and thoroughly examined to meet or surpass industrial standards. The solid installation cable is aimed to offer sturdy wide-ranged cable deployments, including 1000BASE-T Gigabit Ethernet and 100BASE-TX Fast Ethernet.
- Solid bare copper conductor
- Low Smoke Zero Halogen (LSZH/LSOH)
- Color: Grey
- CPR Certified, Fire protection Class: Eca (EN 50575:2014 + A1:2016)
- 500MHz performance
- RoHS compliant
- PoE Power over Ethernet support
- Package:Ｗooden Drum
Product Specification
| Network Cable Type | Bulk cable - CAT 6a - IEEE 802.5 |
| Technology | Unshielded twisted pair (UTP) |
| Jacket Material | Low Smoke Zero Halogen (LSZH) |
| American Wire Gauge (AWG) | 23 |
| Wires per Cable | 8 wires |
| Pairs per Cable | 4 pairs |
| Features | Halogen-free, solid, bare copper conductors, EZ pull box |
| Length | 305 m |
| Colour | Grey |
| Miscellaneous | Miscellaneous |
| Compliant Standards | RoHS, ISO/IEC 11801, ANSI/TIA-568-C.2 - up to 500 MHz |
Features - Equip - 401496
Length
>50m
General
CAT6a
More Details
Product Code
04:238246
EAN Code
4015867202098
Manufacturer
Equip
