Extreme Networks 5420F - Switch - L3 - 48 x 10/100/1000 + 4 x 1 Gigabit / 10 Gigabit SFP+ (uplink) - rack-mountable - PoE (740 W) - AC | 5420F-48P-4XE
5420F-48P-4XE
Find similar
Delivery
Payment options
Please sign in so that we can notify you about a reply
Product Specification
| Device Type | Switch - 48 ports - L3 - stackable |
| Enclosure Type | Rack-mountable |
| Subtype | Gigabit Ethernet |
| Ports | 48 x 10/100/1000 + 4 x 1 Gigabit / 10 Gigabit SFP+ (uplink) |
| Power Over Ethernet (PoE) | PoE |
| PoE Budget | 740 W |
| Performance | Switching capacity: 256 Gbps <br /> Forwarding rate: 190.5 Mpps |
| Capacity | ARP table (IPv4): 16000 <br /> IPv4 routes: 12000 <br /> IP multicast entries: 6000 <br /> ARP table (IPv6): 6000 <br /> IPv6 neighbour table entries: 6000 <br /> ACL entries (ingress): 8000 <br /> ACL entries (egress): 1024 <br /> Maximum number of VLANs: 4094 <br /> IP interfaces: 1533 <br /> Policy profiles: 63 <br /> Unique permit/deny rules per switch: 4024 <br /> ARP table (IPv4): 8000 <br /> IPv4 routes: 11750 <br /> IP multicast entries: 4000 <br /> ARP table (IPv6): 5750 <br /> IPv6 neighbour table entries: 8000 <br /> ACL entries (ingress): 1024 <br /> ACL entries (egress): 336 <br /> Maximum number of VLANs: 4059 <br /> IP interfaces: 248 |
| Features | Mode button, fan module |
| Compliant Standards | IEEE 802.3at, IEEE 802.3bt |
| Expansion / Connectivity | |
| Interfaces | 48 x 1000Base-T RJ-45 30 W <br /> 4 x 10GBase-X SFP+ uplink <br /> 2 x network stack device SFP-DD unpopulated <br /> 1 x management (Gigabit LAN) RJ-45 <br /> 1 x 10/100/1000 Base-T RJ-45 out-of-band network management <br /> 2 x USB Type A management <br /> 1 x console (micro-USB) |
| Power | |
| Power Device | Internal power supply |
| Installed Qty | 1 |
| Max Supported Qty | 2 |
| Power Redundancy | Optional |
| Power Provided | 860 Watt |
| Voltage Required | AC |
| Miscellaneous | |
| Rack Mounting Kit | Included |
| Software / System Requirements | |
| Software Included | Base Software License |
| Dimensions & Weight | |
| Width | 43.2 cm |
| Depth | 33.02 cm |
| Height | 4.32 cm |
| Weight | 5.28 kg |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - lifetime |
