Extreme Networks Summit X450-G2 Series X450-G2-24t-GE4 / Switch / Managed / 24 x 10/100/1000 + 4 x Gigabit SFP / rack-mountable | 16172
Please sign in so that we can notify you about a reply
Product Features
- Summitstack-V84 - high-speed stacking over dedicated stacking ports
The Summit X450-G2 also supports high-speed 84 Gbps stacking, which is ideal for demanding applications where a high volume of traffic traverses through the stacking links, yet bandwidth is not compromised through stacking. SummitStack-V84 is supported over passive copper QSFP cables. SummitStack-V84 is only supported on Summit X450-G2 switches running the same version of ExtremeXOS. - Intelligent switching
Summit X450-G2 supports sophisticated and intelligent Layer 2 switching, as well as Layer 3 IPv4/IPv6 routing including policy-based switching/routing, Provider Bridges, bidirectional ingress and egress Access Control Lists, and bandwidth control by 8 Kbps granularity both for ingress and egress. - IEEE 802.3at PoE-plus
IEEE 802.3af Power over Ethernet has been widely used in the campus enterprise edge network for Ethernet-powered devices such as wireless access points, Voice over IP phones, and security cameras. Ethernet port extenders such as Extreme Networks ReachNXT 100-8t can also utilize PoE, making installation and management easier and reducing maintenance costs. The newer IEEE 802.3at PoEplus standard expands upon Power over Ethernet by increasing the power limit up to 30 watts, and by standardizing power negotiation by using LLDP. Summit X450-G2 supports IEEE 802.3at PoE-plus and supports standards-compliant PoE devices today and into the future. - Role-based policy
Utilizing NetSight Policy Management, the role-based policy framework empowers a network administrator to define distinct roles or profiles that represent industry specific operational groups that may exist in an education or a business environment (e.g., administrator, teacher, student, guest). Each defined role is granted individualized access to specific network services and applications and these access privileges remain associated with users as they move across both wired and wireless network access points. Users can be authenticated via IEEE 802.1X, MAC address, or web authentication, and then assigned a pre-defined operational role. Network operations can be seamlessly tailored to meet business-oriented requirements by providing each role with individualized access to network services and applications, thus aligning network resource utilization with business goals and priorities. - Audio Video Bridging
The X450-G2 series supports IEEE 802.1 Audio Video Bridging (AVB) to enable reliable, real-time audio/video transmission over Ethernet. AVB technology delivers the quality of service required for today's high-definition and time-sensitive multimedia streams.
Special Features
- Secure Network Access through Role-based policy or Identity Management
- Front-to-Back airflow
- Modular PoE power supplies
- 850 W of PoE-Plus budget with 1 PSU
- 1440 W of PoE-Plus Budget with 2 PSUs
- Y.1731 OAM Measurements in hardware for accuracy
- Energy Efficient Ethernet - IEEE 802.3az
Product Specification
| Device Type | Switch - 24 ports - Managed - stackable |
| Enclosure Type | Rack-mountable 1U |
| Subtype | Gigabit Ethernet |
| Ports | 24 x 10/100/1000 + 4 x Gigabit SFP |
| Performance | Aggregate switching bandwidth: 140 Gbps ¦ Forwarding performance: 104.2 Mpps ¦ Latency (64-byte packets): 4 µs |
| Capacity | Virtual interfaces (VLANs): 4094 ¦ QoS hardware queues per port: 8 |
| MAC Address Table Size | 68K entries |
| Jumbo Frame Support | 9216 bytes |
| Features | Traffic shaping, DoS attack prevention, CLEAR-Flow Security Rules Engine, 4MB packet buffer |
| Compliant Standards | IEEE 802.3z, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3az |
| Processor | X MIPS: 1 GHz |
| RAM | 1 GB DDR3 SDRAM |
| Flash Memory | 4 GB |
| Status Indicators | Port status, power, fan |
| Expansion / Connectivity | Expansion / Connectivity |
| Interfaces | 24 x 1000Base-T RJ-45 ¦ 4 x 1000Base-X SFP ¦ 1 x console RJ-45 management ¦ 1 x management (Gigabit LAN) RJ-45 ¦ 1 x USB 2.0 Type A ¦ 2 x network stack device QSFP |
| Power | Power |
| Power Device | Internal power supply - hot-plug |
| Installed Qty | 0 (installed) / 2 (max) |
| Power Redundancy | Optional |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Miscellaneous | Miscellaneous |
| Compliant Standards | TUV GS, C-Tick, CISPR 22 Class A, CISPR 24, IEC 61000-4-11, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, EN55024, CB, AS/NZS 60950-1, EN 61000-4-4, EN 61000-4-3, CCC, EMC, ICES-003 Class A, FCC, EN 61000-4-11, FCC CFR47 Part 15, EN 60950-1, CSA C22.2 No. 60950-1-03, UL 60950-1 Second Edition, KCC, FDA, CDRH, IEC 60950-1 Second Edition, EN 61000-3-2:2006, EN 61000-3-3:2008, VCCI Class A, EN 60825-1:2001, EN 300 386 V1.4.1, EN 61000-4-2:2009, EN 61000-4-5:2006, EN 61000-4-6:2009, EMC 2004/108/EC, LVD 2006/95/EC, 21 CFR 1040.10, IEC 61000-4-2:2008, IEC 61000-4-4:2004, IEC 61000-4-5:2005, IEC 61000-4-6:2008, EN 55022:2006+A1:2007, EN 300386 |
| Software / System Requirements | Software / System Requirements |
| Software Included | ExtremeXOS Edge |
| Dimensions & Weight | Dimensions & Weight |
| Width | 44.2 cm |
| Depth | 48.8 cm |
| Height | 4.4 cm |
| Weight | 6.32 kg |
| Manufacturer Warranty | Manufacturer Warranty |
| Service & Support | Limited warranty - lifetime |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 50 °C |
| Humidity Range Operating | 10 - 95% (non-condensing) |
| Min Storage Temperature | -40 °C |
| Max Storage Temperature | 70 °C |
| Humidity Range Storage | 10 - 95% (non-condensing) |
Features - extreme networks - 16172
More Details
Product Code
3G22070
EAN Code
0644728161720
Manufacturer
extreme networks
