Extreme Networks ExtremeSwitching X460-G2 Series X460-G2-24t-10GE4 / Switch / Managed / 24 x 10/100/1000 + 4 x shared SFP + 4 x SFP + 4 x SFP+ / rack-mountable | 16701

Product Features

• Flexible port configuration
  Summit X460-G2 offers flexible port configurations. For Summit X460-G2 24 port copper models with 10Gb uplinks with four dedicated Gigabit Ethernet fiber ports and four shared Gigabit Ethernet fiber ports, the switch can have up to 8 fiber GbE ports, while still providing 20 Gigabit Ethernet copper ports (PoE-plus or non-PoE). The Summit X460-G2 24 port copper models with 1Gb uplinks can provide up to 12 SFP ports with 20 Gigabit Ethernet ports or eight SFP ports with 24 copper GbE ports.
• High-performance stacking
  Up to eight Summit X460-G2 switches can be stacked using three different methods of stacking: SummitStack. SummitStack-V. and SummitStack-V160.
• Intelligent switching and MPLS/H-VPLS support
  Summit X460-G2 supports sophisticated and intelligent Layer 2 switching, as well as Layer 3 IPv4/IPv6 routing including policy-based switching/routing. Provider Bridges, bidirectional ingress and egress Access Control Lists, and bandwidth control by 8 Kbps granularity both for ingress and egress. To provide scalable network architectures used mainly for Carrier Ethernet network deployment. Summit X460-G2 supports MPLS LSP-based Layer 3 forwarding and Hierarchical VPLS <H-VPLS) for transparent LAN services. With H-VPLS. transparent Layer 3 networks can be extended throughout the Layer 3 network cloud by using a VPLS tunnel between the regional transparent LAN services typically built by Provider Bridges (IEEE 802.1ad) technology.
• IEEE 802.3at PoE-plus
  IEEE 802.3af Power over Ethernet has been widely used in the campus enterprise edge network for Ethernet-powered devices such as wireless access points. Voice over IP phones, and security cameras. Ethernet port extenders such as Extreme Networks ReachNXT'" 100-8t can also utilize PoE. making installation and management easier and reducing maintenance costs. The newer IEEE 802.3at PoE-plus standard expands upon Power over Ethernet by increasing the power limit up to 30 watts, and by standardizing power negotiation by using LLDP. Summit X460-G2 supports IEEE 802.3at PoE-plus and supports standards-compliant PoE devices today and into the future.
• 1588 precision time protocol (PTP)
  Summit X460-G2 offers Boundary Clock (BC). Transparent Clock (TC). and Ordinary Clock (OC) for synchronizing phase and frequency and allowing the network and the connected devices to be synchronized down to microseconds of accuracy over Ethernet connection.
• Audio video bridging (AVB)
  The X460-G2 series supports IEEE 802.1 Audio Video Bridging to enable reliable, real-time audio/video transmission over Ethernet. AVB technology delivers the quality of service required for today's high-definition and time-sensitive multimedia streams.

Special Features

• User policy and host integrity enforcement, and identity management
• Universal Port Dynamic Security Profiles to provide fine granular security policies in the network
• Threat detection and response instrumentation to react to network intrusion with CLEAR-Flow Security Rules Engine
• Denial of Service (DoS) protection and IP security against man-in-the-middle and DoS attacks to harden the network infrastructure
