Extreme Networks Virtual Services Platform 4900 Series VSP4900-24XE - Switch - L3 - Managed - 24 x 1/10GBase-X SFP+ - rack-mountable | VSP4900-24XE-B3
Please sign in so that we can notify you about a reply
Product Features
- Robust performance
With an aggregate switching bandwidth of 680 Gbps and a forwarding rate of 505.9 Mpps, the VSP4900-24XE ensures efficient handling of data across the network, making it suitable for high-demand environments. - Advanced networking capabilities
Supporting Layer 3 advanced switching, the VSP4900-24XE offers a comprehensive set of features such as Quality of Service (QoS), VLAN support, and Link Aggregation Control Protocol (LACP), enhancing network flexibility and efficiency. - Comprehensive security
Equipped with Media Access Control Security (MACsec) and support for Multiple Spanning Tree Protocol (MSTP), the VSP4900-24XE provides a secure networking environment by protecting against threats and ensuring data integrity. - High-capacity connectivity
Featuring 24 1/10GBase-X SFP+ ports, this switch accommodates high-speed connections, making it suitable for data-intensive applications and ensuring high performance across the network. - Durable and reliable
Designed to operate in a wide range of environmental conditions and compliant with numerous standards, the VSP4900-24XE is built for longevity and compliance in diverse operational settings.
Special Fetures
- 680 Gbps aggregate switching bandwidth for high-speed data processing
- 505.9 Mpps forwarding rate to efficiently manage network traffic
- 24 1/10GBase-X SFP+ ports for flexible high-capacity connectivity
- Layer 3 advanced switching with comprehensive network features
- Supports MACsec and MSTP for enhanced network security
Product Specification
| Device Type | Switch - 24 ports - L3 - Managed |
| Enclosure Type | Rack-mountable 1U |
| Subtype | 10 Gigabit Ethernet |
| Ports | 24 x 1/10GBase-X SFP+ |
| Performance | Aggregate switching bandwidth: 680 Gbps <br /> Forwarding rate: 505.9 Mpps |
| Capacity | VLANs supported: 4059 <br /> MSTP instances: 12 <br /> LACP links per group (active): 8 <br /> ARP entries: 32000 <br /> IP routes: 15488 <br /> OSPF interfaces: 500 <br /> BGP peers: 256 <br /> VRF instances: 256 <br /> RIPng interfaces: 48 <br /> OSPFv3 interfaces: 500 <br /> BGPv6 peers: 256 <br /> Mirrored ports: 49 <br /> BEB nodes per VSN: 500 |
| MAC Address Table Size | 80K entries |
| Routing Protocol | RIP-1, RIP-2, BGP, IGMPv2, IGMP, OSPFv2, PIM-SM, IGMPv3, OSPFv3, PIM-SSM, RIPng, BGP+ |
| Features | ARP support, VLAN support, port mirroring, sFlow, MSTP support, QoS, LACP, RSPAN, 2 fans, SPB, EEE, port-based VLAN, VSN support, support IP Shortcut Routing, MACsec, LRM optics support, DvR leaf interfaces |
| Compliant Standards | IEEE 802.3ab, IEEE 802.1ae, IEEE 802.3az, IEEE 802.1aq |
| RAM | 8 GB |
| Flash Memory | 8 GB |
| Expansion / Connectivity | |
| Interfaces | 2 x USB Type A <br /> 1 x serial (console) RJ-45 management <br /> 1 x 1000Base-T RJ-45 management <br /> 1 x console (micro-USB) Type B management <br /> 24 x 1/10GBase-X SFP+ |
| Expansion Slots | 1 (total) / 1 (free) x Versatile Interface Module (VIM) |
| Power | |
| Power Device | Internal power supply - hot-plug |
| Installed Qty | 1 |
| Max Supported Qty | 2 |
| Power Redundancy | Optional |
| Power Redundancy Scheme | 1+1 (with optional power supply) |
| Power Provided | 350 Watt |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Miscellaneous | |
| Included Accessories | 2 x fan modules |
| Rack Mounting Kit | Included |
| Compliant Standards | FCC Class A certified, BSMI, CISPR 24, IEC 61000-4-11, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, SABS, EN55024, CB, AS/NZS 60950-1, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, CCC, ICES-003 Class A, EN 61000-4-5, EN 61000-4-11, Laser Class 1, FCC CFR47 Part 15, EN 61000-4-8, UL 60950-1, IEC 60950-1, EN 60950-1, EN 60825-1, VCCI Class A, EAC, EN 300 386 V1.6.1, RoHS 2011/65/EU, EN 55011 class A, EN 61000-3-3:2013, WEEE 2012/19/EU, EMC 2014/30/EU, EN 61000-3-2:2014, LVD 2014/35/EU, GB 4943.1-2011, CNS 14336-1, EN 62368-1, IEC 62368-1, EN 55032 Class A, ETSI EN 300 019-2-3 V2.1.2, ETSI EN 300 019-2-2 V2.1.2, NRCS, EN/ETSI 300 019-2-1 v2.1.2, EN/ETSI 300 753, ASTM D3580, ACMA RCM, CISPR 32 Class A, CAN/CSA-C22.2 No. 60950-1, UL 62368-1, China RoHS SJ/T 11363-2006, RoHS CNS 15663, FCC CFR21 Part 1040.10, AS/NZS CISPR 32, GB/T9254-2008, CAN/CSA-C22.2 No. 62368-1-14 |
| Dimensions & Weight | |
| Width | 44 cm |
| Depth | 48.8 cm |
| Height | 4.36 cm |
| Weight | 7.66 kg |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 1 year |
| Environmental Parameters | |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 45 °C |
| Humidity Range Operating | 10 - 95% (non-condensing) |
| Min Storage Temperature | -40 °C |
| Max Storage Temperature | 70 °C |
| Humidity Range Storage | 10 - 95% (non-condensing) |
Features - extreme networks - VSP4900-24XE-B3
General
24-Port
More Details
Product Code
3G28936
EAN Code
0644728045082
Manufacturer
extreme networks
