Extreme Networks ExtremeSwitching 5420 Series 5420F-16MW-32P-4XE - Switch - L3 - Managed - 16 x 100/1000/2.5G (PoE++) + 32 x 10/100/1000 (PoE+) + 4 x 1 Gigabit / 10 Gigabit SFP+ (uplink) + 2 x SFP-DD (stackable) - rack-mountable - PoE++ (1862 W) | 5420F-1

Μάρκα: Extreme Networks

Γράψτε μια κριτική

ΚΩΔΙΚΟΣ (SKU):

5420F-16MW-32P-4XE

€11,926.71

€14,192.78 με Φ.Π.Α.

Μη Διαθέσιμο

Στα αγαπημένα Κάνε μια ερώτηση

Product CodeCA83423 EAN Code0644728051977 ManufacturerExtreme Networks

Find similar

Delivery

Payment options

Προδιαγραφές
Χαρακτηριστικά
Κριτικές

Special Fetures

High-performance, feature-rich fixed-form switch for enterprise edge deployments
Universal hardware platform providing end-to-end network segmentation
48-port model with Gigabit and Multi-Gigabit Ethernet connectivity
MACsec on 10/100/1000 access and uplink ports for secure link encryption
Layer 2/Layer 3 Fabric services for secure network segmentation and automation
Non-blocking, wire-speed design

Product Specification

Device Type	Switch - 48 ports - L3 - Managed
Enclosure Type	Rack-mountable
Subtype	Gigabit Ethernet
Ports	16 x 100/1000/2.5G (PoE++) + 32 x 10/100/1000 (PoE+) + 4 x 1 Gigabit / 10 Gigabit SFP+ (uplink) + 2 x SFP-DD (stackable)
Power Over Ethernet (PoE)	PoE++
PoE Budget	1862 W
Performance	Aggregate bandwidth: 304 Gbps ¦ Frame rate: 226.2 Mpps
Max Units In A Stack	8
Remote Management Protocol	CLI
Encryption Algorithm	128-bit AES, 256-bit AES
Features	Auto-sensing per device, half duplex mode, full duplex mode, MACsec support, LRM optics support
Compliant Standards	IEEE 802.1ae, IEEE 802.3at, IEEE 802.3bt
Expansion / Connectivity
Interfaces	16 x 100/1000/2.5G RJ-45 PoE++ - 90 W ¦ 32 x 10/100/1000 Base-T RJ-45 PoE+ - 30 W ¦ 4 x 1/10GBase-X SFP+ uplink ¦ 2 x network stack device SFP-DD ¦ 1 x serial (console) RJ-45 ¦ 1 x management (Gigabit LAN) RJ-45 ¦ 2 x USB ¦ 1 x console (micro-USB)
Power
Power Device	Internal power supply
Installed Qty	1
Max Supported Qty	2
Power Redundancy	Optional
Power Provided	1200 Watt
Voltage Required	AC 100-120/200-240 V
Software / System Requirements
Software Included	Base Software License, ExtremeCloud IQ Pilot (1 year)
Dimensions & Weight
Width	44.1 cm
Depth	33 cm
Height	4.4 cm
Weight	5.3 kg
