FUJITSU PLAN CP Intel I350-T2 / Network adapter / PCIe 2.1 x4 low profile / Gigabit Ethernet x 2 / for PRIMERGY RX1330 M2, RX2530 M1-L, RX2530 M2, RX2540 M1-L, RX2540 M2, TX1320 M2, TX1330 M2 | S26361-F4610-L502

Brand: Fujitsu

CODE (SKU):

S26361-F4610-L502

€108.91

(€129.60 inc. VAT)

Availability: 7 item(s)

Standard delivery within 4 to 8 business days.

Express delivery within 2 to 3 business days.

+ −

Ask a question

Find similar

Delivery

Payment options

Product Code0777ZR8 EAN Code4053026551786 ManufacturerFujitsu

Description
Features

FUJITSU PLAN CP Intel I350-T2 / Network adapter / PCIe 2.1 x4 low profile / Gigabit Ethernet x 2 / for PRIMERGY RX1330 M2, RX2530 M1-L, RX2530 M2, RX2540 M1-L, RX2540 M2, TX1320 M2, TX1330 M2 | S26361-F4610-L502

Description

A networked IT infrastructure that functions and controlling critical business processes in a transported across the network relies on fast and reliable data processing by the network cards. The cards offers at least one Ethernet interface which is designed for the respective network types and network architectures. The bus interface links the network card with the server.

Special Features

Based on the Intel 1 GbE LAN Powerville I350 -AM2 chip
Power management such as Ethernet Efficient Ethernet and DMA Coalescing (DMAC) support
10/100/1000 Mbps
Virtualization support via VMDq and SR-IOV

Product features

Based on the Intel 1 GbE LAN Powerville I350 -AM2 chip
Industry-leading, energy-efficient is designed for 1 Gigabit performance and multi-core processors.
Power management such as Ethernet Efficient Ethernet and DMA Coalescing (DMAC) support
This contributes to increased efficiency and reduces power consumption.
10/100/1000 Mbps
Automatically compatible with Ethernet, fast Ethernet, and Gigabit Ethernet networks.
Virtualization support via VMDq and SR-IOV
Multi-port cards provide the platform with the port density required for virtualized environments.

Product Specification

Device Type	Network adapter
Form Factor	Plug-in card - low profile
Interface (Bus) Type	PCI Express 2.1 x4
PCI Specification Revision	PCIe 2.1
Ports	Gigabit Ethernet x 2
Connectivity Technology	Wired
Cabling Type	Ethernet 10Base-T, Ethernet 100Base-TX, Ethernet 1000Base-T
Data Link Protocol	10Mb LAN, 100Mb LAN, GigE
Data Transfer Rate	1 Gbps
Network / Transport Protocol	TCP/IP, UDP/IP, iSCSI
Status Indicators	Port transmission speed, link/activity
Features	Flow control, auto-negotiation, VLAN support, wake on LAN (WOL), IPv6 support, Jumbo Frames support, Virtual Machine Device Queues (VMDq), IPv4 support, Receive Side Scaling (RSS), Single Root I/O Virtualization (SR-IOV), Link Aggregation Control Protocol (LACP), TCP Segmentation Offload (TSO), PXE 2.0 support, Extended Message-Signaled Interrupts (MSI-X), Precision Time Protocol (PTP)
Compliant Standards	IEEE 802.3u, IEEE 802.3i, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1as, IEEE 802.3az
Processor	1 x I350-AM2 - Intel
Interfaces	2 x 1000Base-T - RJ-45
Included Accessories	Low-profile bracket, full-height bracket
Power Consumption Operational	4.4 Watt
Min Operating Temperature	0 °C
Max Operating Temperature	55 °C
Designed For	Fujitsu PRIMERGY CX120 S1, CX122 S1, CX250 S1, CX250 S2, CX270 S1, CX270 S2, CX272 S1, RX100 S6, RX100 S7, RX100 S7p, RX100 S8, RX1330 M1, RX1330 M2, RX200 S6, RX200 S7, RX200 S8, RX2520 M1, RX2530 M1, RX2530 M1-L, RX2530 M2, RX2540 M1, RX2540 M1-L, RX2540 M2, RX2560 M1, RX300 S6, RX300 S7, RX300 S8, RX350 S7, RX350 S8, RX4770 M1, RX4770 M2, RX500 S7, RX600 S5, RX600 S6, RX900 S1, RX900 S2, SX150 S8 Universal Storage Server, SX350 S8 Universal Storage Server, TX100 S2, TX100 S3, TX100 S3p, TX120 S2, TX120 S3, TX120 S3p, TX1310 M1, TX1320 M1, TX1320 M2, TX1330 M1, TX1330 M2, TX140 S1, TX140 S1p, TX140 S2, TX150 S7, TX150 S8, TX150 S8r, TX200 S6, TX200 S7, TX2540 M1, TX2560 M1, TX300 S6, TX300 S7, TX300 S8
