Hikvision ADS-12FG-12N / Power adapter / AC 100-240 V / 12 Watt / black | ADS-12FG-12N
Please sign in so that we can notify you about a reply
Product Specification
| Device Type | Power adapter - external |
| Colour | Black |
| Power Device | Power Device |
| Input Voltage | AC 100-240 V |
| Input Voltage Range | AC 90 - 264 V |
| Frequency Required | 47 - 63 Hz |
| Output Voltage | 12 V |
| Max Electric Current | 1 A |
| Power Capacity | 12 Watt |
| Efficiency | 82.96% |
| Miscellaneous | Miscellaneous |
| MTBF | 100,000 hours |
| Features | Over current protection, over voltage protection, short-circuit protection |
| Compliant Standards | UL, cUL, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6 |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 40 °C |
| Humidity Range Operating | 10 - 90% (non-condensing) |
| Dimensions & Weight | Dimensions & Weight |
| Width | 3.05 cm |
| Depth | 6.8 cm |
| Height | 4.1 cm |
Features - Hikvision - ADS-12FG-12N
More Details
Product Code
04:374955
EAN Code
5715063004326
Manufacturer
Hikvision
