Homematic IP HmIP-PCBS - Switch circuit board - wireless - 868 - 868.6 MHz, 869.4 - 869.65 MHz | 150776A0
Please sign in so that we can notify you about a reply
Special Fetures
- Thanks to the compact design the device can be flexibly installed into existing devices and own projects
- Connected devices can be switched on and off comfortably via the Homematic IP app or Remote Control
- Application in almost all areas of a smart home - conventional household appliances, light installations or garage door drives are controlled intelligently with Homematic IP
- The miniature relay provides a switching capacity of up to 30 V/1 A
- If the miniature relay is not required it can simply be broken off and only the open collector switching output with 30 V/0.5 A can be used
- Can be used with the Access Point in connection with the Homematic IP app (no recurring costs), the Homematic
- Comfortable and individual voice control (e.g. via Amazon Alexa or Google Assistant)
- For operation, the Homematic IP Access Point in connection with the Homematic IP app (no recurring costs), the Homematic Central Control Unit CCU2 or an appropriate partner solution is required
Product Specification
| Product Type | Switch circuit board |
| Power Source | Hardwired |
| Connectivity Technology | Wireless |
| Max Range Open Space | 350 m |
| Frequency Band | 868 - 868.6 MHz, 869.4 - 869.65 MHz |
| Miscellaneous | |
| Nominal Voltage | DC 5 - 25 V |
| Dimensions & Weight | |
| Width | 2.8 cm |
| Depth | 2.1 cm |
| Height | 4.8 cm |
| Weight | 13 g |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 12.2 cm |
| Shipping Depth | 9.3 cm |
| Shipping Height | 3.6 cm |
| Shipping Weight | 74.2 g |
| Environmental Parameters | |
| Min Operating Temperature | -10 °C |
| Max Operating Temperature | 35 °C |
Features - homematic - 150776A0
More Details
Product Code
07:251800
EAN Code
4047976507764
Manufacturer
homematic
