HP Workstation Z240 / MT / Core i7 6700 / 3.4 GHz / RAM 8 GB / SSD 256 GB / DVD SuperMulti / HD Graphics 530 / GigE / Win 7 Pro 64-bit (Win 10 Pro ) / vPro | J9C17EA#ABD
HP Workstation Z240 / MT / Core i7 6700 / 3.4 GHz / RAM 8 GB / SSD 256 GB / DVD SuperMulti / HD Graphics 530 / GigE / Win 7 Pro 64-bit (Win 10 Pro ) / vPro | J9C17EA#ABD
Description The world's number one ranked entry level workstations features a choice of Tower or SFF configurations. It just got better with the HP Z240 which packs the performance, features, and reliability of a workstation into the price point of a desktop PC. Special Features
Product features
|
Product Specification
Platform Technology | Intel vPro Technology |
Type | Workstation |
Product Form Factor | Mini tower |
Built-in Devices | Speaker |
Embedded Security | Trusted Platform Module (TPM 1.2) Security Chip |
Colour | Black |
Localisation | German / Germany |
CPU | Intel Core i7 (6th Gen) 6700 / 3.4 GHz |
Max Turbo Speed | 4 GHz |
Number of Cores | Quad-Core |
CPU Qty | 1 |
Max CPU Qty | 1 |
CPU Upgradability | Upgradable |
Processor Main Features | Hyper-Threading Technology, Intel Turbo Boost Technology 2, Intel Smart Cache |
CPU Socket | LGA1151 Socket |
Chipset Type | Intel C236 |
Installed Size | 8 MB |
Cache Per Processor | 8 MB |
Installed Size | 8 GB / 64 GB (max) |
Technology | DDR4 SDRAM - non-ECC |
Effective Memory Speed | 2133 MHz |
Rated Memory Speed | 2133 MHz |
Memory Specification Compliance | PC4-17000 |
Form Factor | DIMM 288-pin |
Features | Unbuffered, dual channel memory architecture |
Configuration Features | 2 x 4 GB |
Type | SSD |
Capacity | 1 x 256 GB |
Interface Type | SATA 6Gb/s |
Type | 1 x SATA |
Controller Interface Type | SATA 6Gb/s |
Channel Qty | 4 |
RAID Level | RAID 0, RAID 1 |
Type | DVD±RW (±R DL) / DVD-RAM - SATA |
Monitor Type | None. |
Graphics Processor | Intel HD Graphics 530 Shared Video Memory (UMA) |
Video Interfaces | DVI, DisplayPort |
Max Monitors Supported | 3 |
Compliant Standards | High Definition Audio |
Type | Mouse, keyboard |
Keyboard Name | HP USB Business Slim Keyboard |
Interface | USB |
Technology | Laser |
Interface | USB |
Ethernet Controller | Intel I219LM |
Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
Features | Wake on LAN (WoL), PXE support |
Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.3z, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.1as, IEEE 802.3az |
Bays | 2 (total) / 2 (free) x external 5.25" x 1/2H ¦ 1 (total) / 0 (free) x external 5.25" Slim Line ¦ 2 (total) / 2 (free) x internal 3.5" x 1/3H ¦ 1 (total) / 0 (free) x internal 2.5" x 1/8H |
Slots | 1 (total) / 0 (free) x CPU ¦ 4 (total) / 2 (free) x DIMM 288-pin ¦ 1 (total) / 1 (free) x PCIe 3.0 x16 - full-length, full-height ¦ 1 (total) / 1 (free) x PCIe 3.0 x1 - full-length, full-height ¦ 1 (total) / 1 (free) x PCIe 3.0 x16 - full-length, full-height (x4 mode) ¦ 1 (total) / 1 (free) x PCIe 3.0 x4 - full-length, full-height ¦ 1 (total) / 1 (free) x M.2 Card |
Interfaces | 6 x USB 3.0 (2 front, 4 rear) ¦ 4 x USB 2.0 (2 front, 2 rear) (one of them is Always On) ¦ 1 x headphones/microphone (1 in front) ¦ 1 x headphones (1 in front) ¦ 2 x DisplayPort ¦ 1 x DVI-I ¦ 1 x PS/2 keyboard ¦ 1 x PS/2 mouse ¦ 1 x LAN (Gigabit Ethernet) ¦ 1 x audio line-in ¦ 1 x audio line-out ¦ 1 x microphone |
Compliant Standards | RoHS, WEEE, ACPI 4.0 |
Device Type | Power supply |
Nominal Voltage | AC 120/230 V (50/60 Hz) |
Power Provided | 400 Watt |
Efficiency | 92% |
Power Factor Correction | Yes (active) |
OS Provided | Microsoft Windows 7 Professional 64-bit Edition (available through downgrade rights from Windows 10 Pro) + Windows 10 Pro Licence |
Software | Cyberlink PowerDVD, CyberLink Power2Go, PDF Complete Corporate Edition, HP Performance Advisor, HP PC Hardware Diagnostics UEFI, HP Client Security, HP Remote Graphics Software 7.1 |
Service & Support | Limited warranty - parts and labour - 3 years - on-site |
Width | 17 cm |
Depth | 44.2 cm |
Height | 39.9 cm |
Weight | 8.6 kg |
Min Operating Temperature | 5 °C |
Max Operating Temperature | 35 °C |
Humidity Range Operating | 8 - 85% (non-condensing) |
