HP Workstation Z2 G9 - Tower - 4U - 1 x Core i9 13900K / 3 GHz - RAM 32 GB - SSD 1 TB - HP Z Turbo Drive, NVMe, TLC - RTX A4000 - Gigabit Ethernet - Win 11 Pro | 86D34EA#ABD
86D34EA#ABD
CPU TypeIntel Core i9
Memory Size32GB
Capacity1TB
Product CodeCJ61653
EAN Code0197961782394
ManufacturerHewlett Packard
Find similar
Delivery
Payment options
Please sign in so that we can notify you about a reply
Product Features
- The unrivalled power of the Z mini
Now, get standard low-profile graphics cards in a Z2 Mini, combined with a powerful processor, for smooth design, rendering and simulation. - Designed to evolve
The Z2 Mini is ready to grow with your workflow. A sliding design offers tool-free interior access to standard-sized components, so you can easily swap out graphics card and memory. Easily connect to essential peripherals with plenty of built-in I/O. - Fits anywhere
Create your ideal workspace, whether you're working in the office or at home. With a versatile, contemporary design, place it proudly on your desk, mount it behind your monitor or fix it under your desk, and even take it with you to the office.
Special Fetures
- The unrivalled power of the Z mini
- Designed to evolve
- Fits everywhere
Product Specification
| Type | Workstation |
| Product Form Factor | Tower - 4U |
| Embedded Security | Trusted Platform Module (TPM 2.0) Security Chip |
| Colour | Black |
| Localisation | Language: German / region: Germany |
| Processor / Chipset | |
| CPU | Intel Core i9 (13th Gen) 13900K |
| Clock Speed | 3 GHz (P-core) / 2.2 GHz (E-core) |
| Max Turbo Speed | 5.8 GHz (P-core) / 4.3 GHz (E-core) |
| Number of Cores | 24-core |
| CPU Qty | 1 |
| Max CPU Qty | 1 |
| L2 cache | 32 MB |
| CPU Upgradability | Upgradable |
| Processor Main Features | Hyper-Threading Technology, Intel Turbo Boost Technology 2, Intel Smart Cache, Intel Turbo Boost Max 3.0 |
| CPU Socket | LGA1700 Socket |
| Chipset Type | Intel W680 |
| Cache Memory | |
| Installed Size | L3 Cache - 36 MB |
| Cache Per Processor | 36 MB |
| RAM | |
| Installed Size | 32 GB / 128 GB (max) |
| Technology | DDR5 SDRAM - non-ECC |
| Effective Memory Speed | 4800 MHz |
| Rated Memory Speed | 4800 MHz |
| Form Factor | DIMM 288-pin |
| Slots | 4 (Total) / 2 (empty) |
| Features | Unbuffered, dual channel memory architecture |
| Configuration Features | 2 x 16 GB |
| Hard Drive | |
| Type | SSD - M.2 2280 |
| Capacity | 1 x 1 TB |
| Interface Type | PCI Express 4.0 x4 |
| Features | HP Z Turbo Drive, NVM Express (NVMe), triple-level cell (TLC) |
| Storage Controller | |
| Type | 1 x SATA/NVMe |
| Controller Interface Type | SATA 6Gb/s / PCIe 4.0 x4 (NVMe) |
| Channel Qty | 4 |
| RAID Level | RAID 0, RAID 1 |
| Optical Storage | |
| Type | No optical drive |
| Card Reader | |
| Type | Card reader |
| Supported Flash Memory Cards | SD Memory Card |
| Monitor | |
| Monitor Type | None. |
| Graphics Controller | |
| Interface Type | PCIe 4.0 x16 |
| Multi-GPU Configuration | 1 single GPU card / integrated GPU |
| Graphics Processor | NVIDIA RTX A4000 / Intel UHD Graphics 770 |
| Video Memory | 20 GB GDDR6 SDRAM |
| Video Interfaces | DisplayPort |
| Audio Output | |
| Compliant Standards | High Definition Audio |
| Input Device | |
| Type | Mouse, keyboard |
| Keyboard | |
| Keyboard Name | HP 320K |
| Interface | USB |
| Localization & Layout | German |
| Mouse | |
| Mouse Name | HP 320M |
| Networking | |
| Ethernet Controller | Intel I219-LM |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Features | Wake on LAN (WoL), ACPI support, auto-uplink (auto MDI/MDI-X), PXE 2.1 support, Intel Active Management Technology (AMT) 16 |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.3z, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.1as, IEEE 802.3az |
| Expansion / Connectivity | |
| Bays | 1 (total) / 1 (free) x external 5.25" ¦ 1 (total) / 1 (free) x external 5.25" Slim Line ¦ 2 (total) / 2 (free) x internal 3.5" ¦ 1 (total) / 1 (free) x internal 2.5" |
| Slots | 1 (total) / 0 (free) x PCIe 5.0 x16 - full-length, full-height ¦ 1 (total) / 1 (free) x PCIe 3.0 x4 - full-length, full-height (x1 mode, open ended) ¦ 1 (total) / 1 (free) x PCIe 3.0 x4 - full-length, full-height (open ended) ¦ 1 (total) / 1 (free) x PCIe 3.0 x16 - full-length, full-height (x4 mode) ¦ 3 (total) / 2 (free) x M.2 Card - 2280 ¦ 1 (total) / 1 (free) x M.2 Card - 2230 (PCIe 3.0 x1 mode and Intel CNVi wireless module) |
| Interfaces | 1 x headphones/microphone (1 in front) (CTIA and OMTP headset support) ¦ 6 x USB 3.2 Gen 2 (4 front, 2 rear) (one of them is charging) ¦ 1 x audio line-in ¦ 1 x audio line-out ¦ 6 x DisplayPort 1.4 ¦ 3 x USB 2.0 ¦ 1 x USB 3.2 Gen 1 ¦ 1 x LAN (Gigabit Ethernet) |
| Miscellaneous | |
| Theft/Intrusion Protection | Security lock slot (cable lock sold separately), padlock loop |
| Security Slot Type | Kensington security slot |
| Compliant Standards | RoHS, FIPS 140-2, WEEE, Energy-Related Products (ErP) Lot 6, CECP, SEPA, low halogen |
| Power | |
| Device Type | Power supply |
| Power Provided | 700 Watt |
| Efficiency | 92% |
| Power Factor Correction | Yes (active) |
| Operating System / Software | |
| OS Provided | Windows 11 Pro English / German |
| Software | HP Support Assistant, HP PC Hardware Diagnostics UEFI, HP Driver Packs, HP Image Assistant, HP PC Hardware Diagnostics, HP ZCentral Remote Boost, HP Management Integration Kit for Microsoft System Center Configuration Manager Gen 4, HP Performance Advisor 3.0 |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - parts and labour - 3 years - on-site |
| Dimensions & Weight | |
| Width | 16.9 cm |
| Depth | 38.5 cm |
| Height | 35.6 cm |
| Weight | 7.2 kg |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 51.8 cm |
| Shipping Depth | 29.5 cm |
| Shipping Height | 49 cm |
| Environmental Parameters | |
| Min Operating Temperature | 5 °C |
| Max Operating Temperature | 35 °C |
| Humidity Range Operating | 10 - 85% RH (non-condensing) |
