HPE Aruba AP-635 (RW) - Campus - radio access point - Wi-Fi 6E - ZigBee, Bluetooth - 2.4 GHz, 5 GHz, 6 GHz | R7J27A
Please sign in so that we can notify you about a reply
Product Specification
| Device Type | Radio access point |
| Ruggedized Design | Indoor |
| Width | 22 cm |
| Depth | 22 cm |
| Height | 5 cm |
| Weight | 1.3 kg |
| Networking | |
| Form Factor | External |
| Connectivity Technology | Wireless |
| Data Transfer Rate | 2.4 Gbps |
| Line Coding Format | CCK, 64 QAM, 256 QAM, BPSK, QPSK, 16 QAM, OFDM, 1024 QAM, 4096 QAM, OFDMA |
| Data Link Protocol | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, ZigBee, IEEE 802.11ac, Bluetooth 5.0, IEEE 802.11ax (Wi-Fi 6E) |
| Spread Spectrum Method | OFDM, DSSS, OFDMA |
| Frequency Band | 2.4 GHz, 5 GHz, 6 GHz |
| Performance | Maximum data rate (2.4 GHz): 287 Mbps ¦ Maximum data rate (5 GHz): 1.2 Gbps ¦ Maximum data rate (6 GHz): 2.4 Gbps ¦ Aggregate bandwidth: 3.9 Gbps |
| Capacity | Wireless clients per Wi-Fi radio: 512 ¦ OFDMA units: 8 ¦ BSSIDs per radio: 16 |
| Status Indicators | System, status |
| Features | Auto-uplink (auto MDI/MDI-X), Wi-Fi Multimedia (WMM) support, Trusted Platform Module (TPM), Maximum Ratio Combining (MRC), Low Density Parity Check (LDPC), Transmit Beam-forming (TxBF) ready, Direct Sequence Spread Spectrum (DSSS), Cyclic Delay Diversity (CDD), Space Time Blocking Code (STBC), Advanced Cellular Coexistence (ACC), ClientMatch, cyclic shift diversity (CSD), packet aggregation A-MPDU, packet aggregation A-MSDU, Intelligent Power Monitoring (IPM), Dynamic Frequency Selection (DFS), High-Throughput (HT) support, LED off mode, Energy-Efficient Ethernet (EEE), Orthogonal Frequency Division Multiplexing (OFDM), Aruba AirMatch, 2x2:2 MU-MIMO technology, Very High Throughput (VHT) support, WMM Power Save, security slot (Kensington security lock compatible), Orthogonal Frequency Division Multiple Access (OFDMA), unified AP support, custom deep-sleep mode, High Efficiency (HE) support, Target Wait Time (TWT), Wi-Fi 6E technology |
| Encryption Algorithm | WPA, WPA-Enterprise, WPA3, Opportunistic Wireless Encryption (OWE), WPA2-MPSK, WPA-Personal, CNSA |
| Compliant Standards | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.3at, IEEE 802.11ac, IEEE 802.3bz, IEEE 802.3bt, IEEE 802.11ax, Wi-Fi CERTIFIED 6 |
| Aerial | |
| Antenna | Internal |
| Directivity | Omni-directional |
| Gain Level | 7 dBi |
| Internet of Things (IoT) | |
| Internet of Things (IoT) Compatible | Yes |
| Communications Technology | Bluetooth Low Energy (LE), Zigbee |
| Expansion / Connectivity | |
| Interfaces | 1 x HPE Smart Rate - RJ-45 ¦ 1 x 2.5 GBase-T - RJ-45 ¦ 1 x USB 2.0 - Type A ¦ 1 x console - micro-USB |
| Miscellaneous | |
| Included Accessories | Mounting bracket |
| MTBF | 59 years |
| Compliant Standards | EN 60950, IEC 60950, UL 60950, UL 2043, FCC, EN 60601-1-2, EN 60601-1-1, EMC 2014/30/EU, LVD 2014/35/EU, EN 62368-1, IEC 62368-1, ISED, RED 2014/53/EU |
| Power | |
| Power Over Ethernet (PoE) Supported | PoE |
| Power Consumption Operational | 26.4 Watt |
| Software / System Requirements | |
| OS Required | ArubaOS, InstantOS |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 25 cm |
| Shipping Depth | 24 cm |
| Shipping Height | 8.5 cm |
| Shipping Weight | 1.65 kg |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - lifetime |
| Environmental Parameters | |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 50 °C |
| Humidity Range Operating | 5 - 95% (non-condensing) |
Features - Hewlett Packard - R7J27A
More Details
Product Code
CC75632
EAN Code
0190017492834
Manufacturer
Hewlett Packard
