HPE Aruba Networking CX 6200F 24G 4SFP+ Switch - Switch - Max / Stacking Distance 10 kms - L3 - Managed - 24 x 10/100/1000 + 4 x 100/1000/10G SFP+ - front and side to back - rack-mountable | JL724B
HPE Aruba Networking CX 6200F 24G 4SFP+ Switch - Switch - Max / Stacking Distance 10 kms - L3 - Managed - 24 x 10/100/1000 + 4 x 100/1000/10G SFP+ - front and side to back - rack-mountable | JL724B
€5346.85 inc. VAT
JL724B
Find similar
Delivery
Payment options
Please sign in so that we can notify you about a reply
Product Features
- Aruba central - unified single pane of glass management
Flexible cloud-based or on-premises management for unified network operations of wired, WLAN, SD-WAN, and public cloud infrastructure. Designed to simplify day zero through day two operations with streamlined workflows. Switch management capabilities include configuration, onboarding, monitoring, troubleshooting, and reporting. - Aruba network analytics engine - advanced monitoring and diagnostics
For enhanced visibility and troubleshooting, Aruba's Network Analytics Engine (NAE) automatically interrogates and analyzes events that can impact a networks health. Advanced telemetry and automation provide the ability to easily identify and troubleshoot network, system, application and security related issues easily, through the use of python agents, CLI-based agents, and REST APIs. The Time Series Database (TSDB) stores configuration and operational state data, making it available to quickly resolve network issues. - Aruba NetEdit - automated switch configuration and management
The entire HPE Aruba Networking CX portfolio empowers IT teams to orchestrate multiple switch configuration changes for smooth end-to-end service rollouts. Aruba NetEdit introduces automation that allows for rapid network-wide changes, and ensures policy conformance post network updates. Intelligent capabilities include search, edit, validation (including conformance checking), deployment and audit features. - Mobility and IoT performance
The HPE Aruba Networking CX 6200 Switch Series uses a fully distributed architecture that utilizes the Gen7 Aruba ASICs. This ensures that the switches offer very low latency, increased packet buffering, and adaptive power consumption. All switching and routing are wire-speed to meet the demands of bandwidth-intensive applications today and in the future. - VSF stacking - scale and simplicity
The Aruba Virtual Switching Framework (VSF) allows you to quickly grow your network using high performance front plane stacking.
Special Fetures
- Enterprise-class connectivity with support for ACLs, robust QoS and common protocols such as static and Access OSPF routing Scalability with 8-member switch VSF stacking
- Scalability with 8-member switch VSF stacking
- Versatile 1G/10G uplinks with LRM and MACsec 256 support on modular switches
- Convenient built-in 1G/10G uplinks on fixed power switches and additional cost-efficient 1G uplink switch models
- Intelligent monitoring, visibility, and troubleshooting with Aruba Network Analytics Engine
- Manage via single pane of glass with Aruba Central across wired, wireless, and WAN
- Simple, one touch deployment with the Aruba CX Mobile App
- Automated configuration and verification with Aruba NetEdit
- Secure and simple access for users and IoT with Aruba Dynamic Segmentation
Product Specification
| Device Type | Switch - 24 ports - L3 - Managed - stackable |
| Enclosure Type | Front and side to back rack-mountable 1U |
| Subtype | Gigabit Ethernet |
| Ports | 24 x 10/100/1000 + 4 x 100/1000/10G SFP+ |
| Performance | Switching capacity: 128 Gbps ¦ Throughput: 95.2 Mpps ¦ Latency (1 Gbps): 2.28 µs ¦ Latency (10 Gbps): 1.46 µs ¦ Stacking bandwidth: 40 Gbps |
| Capacity | Packet buffer size: 8 MB ¦ IPv4 ACL entries (ingress): 5120 ¦ IPv6 ACL entries (ingress): 1280 ¦ MAC ACL entries (ingress): 5120 ¦ IPv4 ACL entries (egress): 2048 ¦ IPv6 ACL entries (egress): 512 ¦ MAC ACL entries (egress): 2048 ¦ IPv4 host table capacity: 8192 ¦ IPv6 host table capacity: 8192 ¦ IPv4 routes (Unicast): 2048 ¦ IPv6 routes (Unicast): 1024 ¦ IGMP groups: 1024 ¦ MLD groups: 1024 |
| MAC Address Table Size | 32768 entries |
| Jumbo Frame Support | 9220 bytes |
| Max Units In A Stack | 8 |
| Routing Protocol | RIP-2, IGMPv2, IGMP, OSPFv2, IGMPv3, OSPFv3, MLDv2, MLD |
| Remote Management Protocol | RMON, CLI, MIB |
| Encryption Algorithm | SSL, FIPS 140-2 |
| Authentication Method | Secure Shell (SSH), RADIUS, TACACS+, Secure Shell v.2 (SSH2) |
| Features | Virtual Route Redundancy Protocol (VRRP) support, Uni-Directional Link Detection (UDLD), Deficit Weighted Round Robin (DWRR), Class of Service (CoS), Type of Service (ToS), Bridge protocol data unit (BPDU), Rapid PVST+ (RPVST+), Link Layer Discovery Protocol, Unsupported Transceiver Mode (UTM), Egress Queue Shaping (EQS), Address Resolution Protocol |
| Compliant Standards | IEEE 802.3, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.1w, IEEE 802.1s, IEEE 802.1t, IEEE 802.1v, IEEE 802.1ab (LLDP), IEEE 802.1ak, IEEE 802.1AX |
| Processor | 1 x ARM Cortex-A72: 1.8 GHz |
| RAM | 8 GB DDR4 SDRAM |
| Flash Memory | 16 GB |
| Expansion / Connectivity | |
| Interfaces | 24 x 10/100/1000 Base-T RJ-45 ¦ 4 x 100/1000/10G SFP+ uplink/stacking ¦ 1 x USB-C console ¦ 1 x console RJ-45 ¦ 1 x management ¦ 1 x USB Type A host |
| Power | |
| Power Device | Internal power supply |
| Voltage Required | AC 100-120/200-240 V (50/60 Hz) |
| 80 PLUS Certification | 80 PLUS Silver |
| Miscellaneous | |
| Included Accessories | 2-Post Rack Kit |
| Compliant Standards | EN 61000-3-2, IEC 61000-3-2, IEC 61000-3-3, IEC 61000-4-11, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, EN 61000-3-3, Laser Class 1, EN 61000-3-3:2013, EN 60825-1:2014, IEC 62368-1: 2014 Second Edition, EN 62368-1:2014+A11:2017, EN 61000-3-2:2019, IEC 60825-1:2014 Class 1, CISPR 35: 2016, UL 62368-1 Third Edition, EN 62368-1:2020+A11:2020, KS C 9832, IEC 62368-1:2018 Third Edition, EN 55035:2017+A11:2020, CNS 15598-1:2020, CNS 15936: 2020 Class A, CAN/CSA C22.2 No. 62368-1:19 Third Edition, GB 4943.1-2022, EN 55032:2015 /A11:2020, Class A, FCC 47 CFR part 15B:2021 Class A, ICES-003 Issue 7: 2020 Class A, VCCI-CISPR 32 Class A, CISPR 32:2016 Class A, AS/NZS CISPR 32:2015 Class A |
| Localisation | English / Europe |
| Software / System Requirements | |
| OS Required | AOS-CX |
| Dimensions & Weight | |
| Width | 44.25 cm |
| Depth | 28.45 cm |
| Height | 4.37 cm |
| Weight | 3.77 kg |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - lifetime |
| Environmental Parameters | |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 45 °C |
| Humidity Range Operating | 5 - 95% (non-condensing) |
| Min Storage Temperature | -40 °C |
| Max Storage Temperature | 70 °C |
| Humidity Range Storage | 5 - 95% (non-condensing) |
Features - Hewlett Packard - JL724B
General
24-Port
More Details
Product Code
CH43788
EAN Code
0190017637938
Manufacturer
Hewlett Packard
No posts found
