HPE Aruba Instant ON AP25 (RW) / Radio access point / Wi-Fi 6, Bluetooth / 2.4 GHz, 5 GHz / cloud-managed / BTO / wall / ceiling mountable | R9B28A
Product Features
- Incredible efficiency with Wi-Fi 6
The Aruba Instant On AP25 Access Points support the Wi-Fi 6 standard, including features such as orthogonal frequency-division multiple access (OFDMA) and Multi-User MIMO (MU-MIMO), and Target Wait Time (TWT). Aruba Instant On AP25 Access Points support features Target Wake Time (TWT) that helps establish a schedule when clients need to communicate with an access point - improving efficiency for longer battery life. The Aruba Instant On AP25 Access Points are 100% backward compatible, allowing businesses to support multiple clients (Wi-Fi 6) and legacy (11a/b/g/n/ac) at the same time. - Higher performance and superior coverage
The Aruba Instant On AP25 Access Points deliver higher capacity, efficiency, and performance to small and growing businesses with device-dense environments. High-performance Aruba Instant On AP25 Access Points bring powerful 4 spatial streams for superior Wi-Fi coverage. Performance benefits of Orthogonal Frequency Division Multiple Access (OFDMA) are improved, meaning increased network performance and network capacity. 160 MHz channel bandwidth delivers increased mesh throughput and Wi-Fi speed ideal for high-def video streaming and virtual reality devices. 2.5G Ethernet uplink port enhances wireless connectivity. - Safeguard sensitive data with WPA2/WPA3 and Enhanced Open
Aruba Instant On AP25 Access Points come with integrated Wi-Fi Alliance security standard WPA2/WPA3 and Enhanced Open support for protected wireless access. Aruba Instant On AP25 Access Points feature integrated router, gateway, and firewall functionality. Aruba Instant On supports Two-Factor Authentication (2FA) for additional layer of authentication, preventing attackers from remotely accessing your networks. Create up to eight different SSIDs under one network name to keep your data safe, whether surfing the web or checking HR data.
Special Features
- Provides a high performance Dual Radio 802.11ax AP with 4 spatial streams (4X4) for higher capacity and coverage
- Includes 2.5G Ethernet uplink port and 160 MHz channel bandwidth for increased wireless throughput
- Wi-Fi 6 certification supports all mandatory 802.11ax features that include MU-MIMO, OFDMA, TWT, and more
- Support for WPA2/WPA3 protected employee and guest login with Enhanced Open for per user guest access
Product Specification
Device Type | Radio access point |
Ruggedized Design | Indoor |
Width | 20.3 cm |
Height | 5.1 cm |
Weight | 1.18 kg |
Networking | Networking |
Form Factor | Wall / ceiling mountable |
Connectivity Technology | Wireless |
Line Coding Format | 1024 QAM |
Data Link Protocol | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, 802.11ax, Bluetooth LE |
Spread Spectrum Method | OFDMA |
Network / Transport Protocol | PPPoE |
Cloud-Managed | Yes |
Frequency Band | 2.4 GHz, 5 GHz |
Performance | Maximum data rate (5 GHz): 4.8 Gbps ¦ Maximum data rate (2.4 GHz): 574 Mbps ¦ Aggregate bandwidth: 5.3 Gbps |
Status Indicators | Status, reset |
Features | Wall mountable, static IP mode, Trusted Platform Module (TPM), reset button, Low Density Parity Check (LDPC), Transmit Beam-forming (TxBF) ready, security lock slot (cable lock sold separately), Advanced Cellular Coexistence (ACC), MU-MIMO technology, 4x4:4 streams, 4x4:4 MU-MIMO technology, 2-factor authentication, security slot (Kensington security lock compatible), Bluetooth (BLE) clients support, Orthogonal Frequency Division Multiple Access (OFDMA), Target Wait Time (TWT), Smart Mesh technology, 160MHz bandwidth support, BSS Coloring, Target Wake Time (TWT), multi-site management |
Encryption Algorithm | WPA2, WPA3 |
Compliant Standards | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.3at, IEEE 802.11ac, IEEE 802.11ax, Wi-Fi CERTIFIED 6 |
Aerial | Aerial |
Antenna | Internal |
Antenna Qty | 2 |
Directivity | Omni-directional |
Gain Level | 4.55 dBi |
Internet of Things (IoT) | Internet of Things (IoT) |
Internet of Things (IoT) Compatible | Yes |
Communications Technology | Bluetooth Low Energy (LE) |
Expansion / Connectivity | Expansion / Connectivity |
Interfaces | 1 x 2.5GBase-T (uplink, PoE) - RJ-45 - 20.1 W |
Miscellaneous | Miscellaneous |
Included Accessories | Wall/ceiling rail mounting clip |
Cables Included | 1 x network cable |
MTBF | 76 years |
Compliant Standards | EN 60601-1-2, EN 60601-1-1, WFA |
Pricing Type | BTO |
Power | Power |
Power Over Ethernet (PoE) Supported | PoE |
Software / System Requirements | Software / System Requirements |
Software Included | InstantOn |
Manufacturer Warranty | Manufacturer Warranty |
Service & Support | Limited warranty - 2 years ¦ Technical support - phone consulting - 90 days from date of purchase ¦ Technical support - web support - 2 years |
Environmental Parameters | Environmental Parameters |
Min Operating Temperature | 0 °C |
Max Operating Temperature | 40 °C |
