Intel Ethernet Server Adapter XL710-QDA1 / Network adapter / OCP 2.0 / 40 Gigabit QSFP+ x 1 | XL710QDA1OCP
Description
The Intel Ethernet Server Adapter X710-DA2 for OCP is part of the Intel Ethernet 700 Series Network Adapters. These adapters are the foundation for server connectivity, providing broad interoperability, critical performance optimizations, and increased agility for Telecommunications, Cloud, and Enterprise IT network solutions.
Product Specification
| Device Type | Network adapter |
| Form Factor | Plug-in card |
| Interface (Bus) Type | Open Compute Project mezzanine (OCP) 2.0 |
| PCI Specification Revision | PCIe 3.0 |
| Ports | 40 Gigabit QSFP+ x 1 |
| Connectivity Technology | Wired |
| Data Link Protocol | 10 Gigabit Ethernet, 40 Gigabit Ethernet |
| Data Transfer Rate | 40 Gbps |
| Capacity | VLAN tags: up to 4096 |
| Network / Transport Protocol | TCP/IP, UDP/IP, iSCSI, SMB, NFS |
| Remote Management Protocol | SNMP, RMON, IPMI 1.0 |
| Status Indicators | Port transmission speed, link/activity |
| Features | VLAN support, manageable, Virtual Machine Device Queues (VMDq), PXE support, Large Receive Offload (LRO), UEFI support, Single Root I/O Virtualization (SR-IOV), TCP Segmentation Offload (TSO), tagged VLAN, checksum offload support, Extended Message-Signaled Interrupts (MSI-X), iSCSI remote boot, Generic Routing Encapsulation (GRE), Data Direct I/O Technology (DDIO), NAS support, Virtual Ethernet Port Aggregator (VEPA), Virtual Extensible LAN (VXLAN), Virtual Ethernet Bridge (VEB), Intel Flow Director, Flexible Port Partitioning (FPP), intelligent offloads, Advanced Packet Filtering, Data Plane Development Kit (DPDK) |
| Compliant Standards | IEEE 802.3, IEEE 802.1Q, IEEE 802.3ad (LACP), IEEE 802.1as, IEEE 802.1Qbg, OCP 2.0 |
| Processor | 1 x Intel XL710-BM2 |
| Interfaces | 1 x 40Gb Ethernet - QSFP+ |
| Compliant Standards | FCC Class A certified, UL, VCCI, C-Tick, BSMI, RoHS, KCC, Directive 2011/65/EU, MSA SFF-8436, IEEE 1588 |
| OS Required | SuSE Linux Enterprise Server 11, SuSE Linux Enterprise Server 12, Red Hat Enterprise Linux 7.3, Linux Kernel 4.4 |
| Service & Support | Limited warranty - lifetime ¦ Limited warranty - money back guarantee - 90 days |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 55 °C |
Features - Intel - XL710QDA1OCP
More Details
Product Code
1358953
EAN Code
5032037088138
Manufacturer
Intel
