Intel Next Unit of Computing Kit 11 Pro Kit / NUC11TNHv70L / Barebone / mini PC / 1 x Core i7 1185G7 / 3 GHz / RAM 0 GB / Intel Iris Xe Graphics / GigE, 2.5 GigE / WLAN: 802.11a/b/g/n/ac/ax, Bluetooth 5.1 | BNUC11TNHV70L00
Please sign in so that we can notify you about a reply
Product Features
- Pint-sized power
The Intel NUC is a mini PC with the power of a desktop, packing features for entertainment, gaming, and productivity in a 4x4 form factor. - Energy optimized, media savvy
With Intel NUC, you get an immersive media experience and responsive interaction while consuming a small amount of power relative to a full-sized PC. - Flexibility for future growth
Due to its portable size and ease of installation, the Intel NUC makes it easy to add devices and scale up rapidly based on changing productivity needs.
Special Features
- Pint-sized power
- Energy optimized, media savvy
- Flexibility for future growth
Product Specification
| Type | PC barebone |
| Product Form Factor | Mini PC |
| Embedded Security | Trusted Platform Module (TPM 2.0) Security Chip |
| Processor / Chipset | Processor / Chipset |
| CPU | Intel Core i7 (11th Gen) 1185G7 |
| Clock Speed | 3 GHz |
| Max Turbo Speed | 4.8 GHz |
| Number of Cores | Quad-Core |
| CPU Qty | 1 |
| Max CPU Qty | 1 |
| CPU Upgradability | Not upgradable |
| Processor Main Features | Hyper-Threading Technology, Intel Virtualization Technology, Intel Turbo Boost Technology 2, Intel 64 Technology, Intel AES New Instructions, Intel Virtualization Technology for Directed I/O, Intel Virtualization Technology with Extended Page Tables |
| Cache Memory | Cache Memory |
| Installed Size | 12 MB |
| Cache Per Processor | 12 MB |
| RAM | RAM |
| Installed Size | 0 GB / 64 GB (max) |
| Technology | DDR4 SDRAM |
| Rated Memory Speed | 3200 MHz |
| Form Factor | SO-DIMM 260-pin |
| Slots | 2 (Total) / 2 (empty) |
| Features | Dual channel memory architecture |
| Hard Drive | Hard Drive |
| Type | No HDD |
| Storage Controller | Storage Controller |
| Type | 1 x NVMe |
| Controller Interface Type | PCI Express 3.0 x4 (NVMe) |
| Optical Storage | Optical Storage |
| Type | No optical drive |
| Monitor | Monitor |
| Monitor Type | None. |
| Graphics Controller | Graphics Controller |
| Graphics Processor | Intel Iris Xe Graphics |
| Video Interfaces | HDMI, USB-C |
| Max Monitors Supported | 4 |
| Audio Output | Audio Output |
| Sound Output Mode | 7.1 channel surround |
| Compliant Standards | High Definition Audio |
| Networking | Networking |
| Ethernet Ports | 2.5 Gigabit Ethernet |
| Ethernet Controller | Intel I225-LM |
| Wireless LAN Supported | Yes |
| Wireless NIC | Intel Wi-Fi 6 AX 201 |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, 2.5 Gigabit Ethernet, Bluetooth 5.0, 802.11ax, Bluetooth 5.1 |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.1as, IEEE 802.11n, IEEE 802.11ac, IEEE 802.1BR, IEEE 802.1Qav, IEEE 802.3bz, IEEE 802.11ax, Bluetooth 5.1, IEEE 802.1Qbv, IEEE 802.1Qbu |
| Expansion / Connectivity | Expansion / Connectivity |
| Bays | 1 (total) / 1 (free) x internal 2.5" |
| Slots | 1 (total) / 1 (free) x M.2 Card - 2280 (Key M) ¦ 1 (total) / 1 (free) x M.2 Card - 2242 (Key B) ¦ 1 (total) / 0 (free) x M.2 Card - 2230 (Key E) |
| Interfaces | 2 x Thunderbolt/USB4 ¦ 2 x HDMI ¦ 2 x LAN (Gigabit Ethernet) ¦ 3 x USB 3.2 Gen 2 - Type A (2 front, 1 rear) ¦ 3 x USB 2.0 - Type A (3 rear) |
| Miscellaneous | Miscellaneous |
| Compliant Standards | BSMI, ICES-003, EN55024, FCC Part 15 B, FCC Part 15 C, RoHS, FCC Part 15 E, BSMI CNS 13438, REACH, EN 300.440, EN 300 328, EN 301 489-1, KN32, KN35, EN 301 893, IEC/EN/UL 60950-1, EN 55032, EN 301 489-3, IEC/EN/UL 62368-1, EN 301 489-17, ARPANSA, AS/NZS CISPR 32, VCCI 32 |
| Power | Power |
| Device Type | Power adapter |
| Voltage Required | DC 19 V |
| Manufacturer Warranty | Manufacturer Warranty |
| Service & Support | Limited warranty - 3 years |
| Dimensions & Weight | Dimensions & Weight |
| Width | 11.7 cm |
| Depth | 11.2 cm |
| Height | 5.4 cm |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 40 °C |
Features - Intel - BNUC11TNHV70L00
CPU Type
- Intel Core i7
More Details
Product Code
07:129092
EAN Code
5032037205351
Manufacturer
Intel
