Intel NUC Kit NUC6CAYH / Barebone / mini PC / Celeron J3455 / 1.5 GHz / HD Graphics 500 / GigE / WLAN, Bluetooth 4.2 | BOXNUC6CAYH
Intel NUC Kit NUC6CAYH / Barebone / mini PC / Celeron J3455 / 1.5 GHz / HD Graphics 500 / GigE / WLAN, Bluetooth 4.2 | BOXNUC6CAYH
Description Intel NUC Kit NUC6CAYH built with a quad-core Intel Celeron processor, delivers cost-efficient Intel-level performance in a fully customizable kit that makes it perfect for basic 4K digital signage, PC replacement, or thin client. This kit gives you the choice to install the OS, memory, and hard drive you want so you can create the exact system that you need. The features include a dual-array front mic and a multi-color LED ring so you can customize your NUC with the look you want. And there's 4K display support via a full-sized HDMI 2.0 port, so you can have 4K digital signs at a cost-effective price point. Intel NUC Kit NUC6CAYH / Barebone / mini PC / Celeron J3455 | BOXNUC6CAYHSpecial Features
Product features
|
Product Specification
Type | PC barebone |
Product Form Factor | Mini PC |
Built-in Devices | Infrared receiver |
CPU | Intel Celeron J3455 / 1.5 GHz |
Max Turbo Speed | 2.3 GHz |
Number of Cores | Quad-Core |
CPU Qty | 1 |
Max CPU Qty | 1 |
Processor Main Features | Intel Virtualization Technology, Intel AES New Instructions |
Installed Size | 2 MB |
Cache Per Processor | 2 MB |
Installed Size | 0 MB / 8 GB (max) |
Technology | DDR3L SDRAM |
Form Factor | SO-DIMM 204-pin |
Features | Dual channel memory architecture |
Type | No HDD |
Type | 1 x SATA |
Controller Interface Type | SATA 6Gb/s |
Type | Card reader |
Supported Flash Memory Cards | SDXC UHS-I Memory Card |
Monitor Type | None. |
Graphics Processor | Intel HD Graphics 500 |
Video Interfaces | VGA, HDMI |
Max Monitors Supported | 2 |
Sound Output Mode | 7.1 channel surround |
Compliant Standards | High Definition Audio |
Wireless LAN Supported | Yes |
Wireless NIC | Intel Dual Band Wireless-AC 3168 |
Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, Bluetooth 4.2 |
Compliant Standards | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, Bluetooth 4.2 |
Bays | 1 (total) / 1 (free) x internal 2.5" |
Slots | 2 (total) / 2 (free) x SO-DIMM 204-pin |
Interfaces | 4 x USB 3.0 - Type A (2 front, 2 rear) (one of them is fast-charging) ¦ 2 x USB 2.0 (2 internal) ¦ 1 x HDMI ¦ 1 x headphones/microphone - mini-jack ¦ 1 x LAN (Gigabit Ethernet) - RJ-45 ¦ 1 x VGA ¦ 1 x TOSLINK output ¦ 1 x SATA-600 (1 internal) |
Included Accessories | VESA mounting kit, processor badge |
Theft/Intrusion Protection | Security lock slot (cable lock sold separately) |
Compliant Standards | ACPI |
Device Type | Power adapter |
Power Provided | 65 Watt |
Service & Support | Limited warranty - 3 years |
Width | 11.5 cm |
Depth | 11.1 cm |
Height | 5.1 cm |
