Intel Wi-Fi 6E AX1690i / Network adapter / M.2 2230 (CNVio2) / Wi-Fi 6E, Bluetooth 5.3 | AX411.NGWG.NVX
Please sign in so that we can notify you about a reply
Special Features
- Impressive network flexibility
- Fast speed
- Reduced latency
- Wi-Fi 6E connectivity
- Bluetooth connectivity
- Intel Double Connect technology
- Intel Active Management technology
Product Specification
| Device Type | Network adapter |
| Form Factor | Plug-in card |
| Interface (Bus) Type | M.2 2230 (CNVio2) |
| Networking | Networking |
| Connectivity Technology | Wireless |
| Data Link Protocol | IEEE 802.11ax (Wi-Fi 6E), IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, Bluetooth 5.3 |
| Spread Spectrum Method | OFDMA |
| Data Transfer Rate | 3 Gbps |
| Line Coding Format | OFDMA, 1024 QAM |
| Frequency Band | 2.4 GHz, 5 GHz, 6 GHz |
| Features | 2x2 MU-MIMO technology, isochronous channel support, WMM support, WMM Power Save, Wi-Fi Direct, Wi-Fi Agile Multiband, 802.1x authentication, 160MHz bandwidth support |
| Compliant Standards | Wi-Fi CERTIFIED 6E, Bluetooth 5.3, IEEE 802.11ax, IEEE 802.11, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11d, IEEE 802.11e, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11u, IEEE 802.11v, IEEE 802.11w, IEEE 802.11az, IEEE 802.1x |
| Miscellaneous | Miscellaneous |
| Encryption Algorithm | FIPS 140-2, WPA3, WPA2, 128-bit AES-CCMP, 256-bit AES-GCMP, EAP-AKA, EAP-SIM, EAP-TLS, EAP-TTLS, MSCHAPv2, PEAP |
| Compliant Standards | FISMA, UEFI, UL, cUL, CB, IEC 60950-1 |
| Software / System Requirements | Software / System Requirements |
| OS Required | Windows 11, Windows 10 64-bit Edition, Linux |
| Dimensions & Weight | Dimensions & Weight |
| Width | 3 cm |
| Depth | 2.2 cm |
| Height | 0.24 cm |
| Weight | 2.83 g |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 80 °C |
| Humidity Range Operating | 50 - 90% (non-condensing) |
Features - Intel - AX411.NGWG.NVX
More Details
Product Code
07:21231272
EAN Code
0675901945004
Manufacturer
Intel
