Intellinet 24-Port Gigabit Ethernet Switch with 2 SFP Ports, 24 x 10/100/1000 Mbps RJ45 Ports + 2 x SFP, IEEE 802.3az (Energy Efficient Ethernet), 19" Rackmount, Metal (Euro 2-pin plug) - Switch - unmanaged - 24 x 10/100/1000 + 2 x Gigabit SFP - desktop,
Please sign in so that we can notify you about a reply
Special Fetures
- 10/100/1000 auto-sensing ports automatically detect optimal network speeds
- Two small form-factor pluggable GBIC module slots (SFP)
- All RJ45 ports with Auto-MDIX (auto uplink) support
- Supports NWay auto-negotiation
- Store and forward switching architecture
- Full/half duplex operation
- Complies with the IEEE 802.3az (Energy Efficient Ethernet EEE) specification
- Green Ethernet power-saving technology deactivates unused ports and adjusts power levels based on the cable length
- Supports 802.3x flow control for full duplex mode and collision-based backpressure for half duplex mode
- Supports Jumbo frames 9 kBytes
- 512 kBytes buffer memory
- Supports up to 8K MAC address entries
- Fanless design ideal for silent operation
- Supports MAC address auto-learning and auto-aging
Product Specification
| Device Type | Switch - 24 ports - unmanaged |
| Enclosure Type | Desktop, rack-mountable 1U |
| Subtype | Gigabit Ethernet |
| Ports | 24 x 10/100/1000 + 2 x Gigabit SFP |
| Performance | Switching capacity: 52 Gbps |
| MAC Address Table Size | 8K entries |
| Features | Flow control, auto-negotiation, store and forward, half duplex mode, full duplex mode, Energy Efficient Ethernet, 512KB packet buffer |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3az |
| Status Indicators | Port transmission speed, power, link/activity |
| Expansion / Connectivity | |
| Interfaces | 24 x 1000Base-T RJ-45 ¦ 2 x 1000Base-X SFP |
| Power | |
| Power Device | Internal power supply |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Power Consumption Operational | 20 Watt |
| Miscellaneous | |
| Rack Mounting Kit | Included |
| Compliant Standards | FCC Class A certified |
| Dimensions & Weight | |
| Width | 44 cm |
| Depth | 20.8 cm |
| Height | 4.4 cm |
| Weight | 3 kg |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Environmental Parameters | |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 40 °C |
| Humidity Range Operating | 10 - 90% (non-condensing) |
| Min Storage Temperature | -10 °C |
| Max Storage Temperature | 70 °C |
Features - Intellinet - 561044
General
24-Port
More Details
Product Code
04:195719
EAN Code
0766623561044
Manufacturer
Intellinet
