j5create JCD552 / Docking station / USB-C 3.2 Gen 2 x 2 / HDMI, DP / GigE | JCD552-N
Please sign in so that we can notify you about a reply
Product Specification
| Product Type | Docking station |
| Width | 8 cm |
| Depth | 31.8 cm |
| Height | 2.6 cm |
| Weight | 378 g |
| Enclosure Colour | Grey, black |
| Storage | Storage |
| Storage Controller | SATA-600 / NVMe |
| Video | Video |
| Max Resolution Details | 3840 x 2160 - 60 Hz |
| Networking | Networking |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Expansion / Connectivity | Expansion / Connectivity |
| Expansion Slots | 1 (total) / 1 (free) x M.2 (PCI Express / SATA) - M.2 2280 ¦ 1 (total) / 1 (free) x microSD ¦ 1 (total) / 1 (free) x SD Memory Card |
| Interfaces | 1 x audio / video - HDMI - 19 pin HDMI Type A ¦ 1 x audio / video - DisplayPort - 20 pin DisplayPort ¦ 2 x USB 3.2 Gen 2 - 9 pin USB Type A ¦ 1 x USB 3.2 Gen 1 - 9 pin USB Type A ¦ 1 x network - 1000Base-T - RJ-45 ¦ 1 x USB-C 3.2 Gen 2 - 24 pin USB-C ¦ 1 x USB-C with Power Delivery (100 W) - 24 pin USB-C |
| Miscellaneous | Miscellaneous |
| Cables Included | 2 x USB-C cable - integrated - 15 cm |
| Features | Security lock slot (cable lock sold separately), USB powered, DisplayPort Alt Mode, 100W power delivery, aluminium housing |
| Security Slot Type | Kensington security slot |
| Compliant Standards | USB Power Delivery 3.0 |
| Manufacturer Warranty | Manufacturer Warranty |
| Service & Support | Limited warranty - 2 years |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 48 °C |
Features - J5CREATE - JCD552-N
More Details
Product Code
CE58452
EAN Code
4712795086133
Manufacturer
J5CREATE
