LANCOM GS-4530XUP - Switch - L3 - Managed - 24 x 100/1000/2.5G (PoE++) + 4 x 10 Gigabit SFP+ + 2 x 40 Gigabit QSFP+ - front to back airflow - desktop, rack-mountable - PoE++ (720 W) | 61883
Please sign in so that we can notify you about a reply
Product Specification
| Device Type | Switch - 24 ports - L3 - Managed |
| Enclosure Type | Front to back airflow desktop, rack-mountable 1U |
| Subtype | 2.5 Gigabit Ethernet |
| Ports | 24 x 100/1000/2.5G (PoE++) + 4 x 10 Gigabit SFP+ + 2 x 40 Gigabit QSFP+ |
| Power Over Ethernet (PoE) | PoE++ |
| PoE Budget | 720 W |
| Performance | Throughput: 360 Gbps ¦ Maximum packet throughput: 267 Mpps ¦ Latency: 4 µs |
| Capacity | Packet buffer size: 4 MB ¦ Virtual interfaces (VLANs): 4093 ¦ IGMP multicast groups: 1024 |
| MAC Address Table Size | 32K entries |
| Jumbo Frame Support | 12288 bytes |
| Routing Protocol | IGMPv2, IGMP, VRRP, IGMPv3, static IPv4 routing, static IPv6 routing, MLDv2, MLD, STP, VRF |
| Remote Management Protocol | RMON, SNMP 3, SSH, CLI, DHCP, Web GUI, LANtools |
| Encryption Algorithm | SSL |
| Authentication Method | RADIUS, TACACS+ |
| Features | DoS attack prevention, MAC address filtering, IPv6 support, IP address filtering, firmware upgradable, DHCP snooping, Jumbo Frames support, DHCP server, IPv4 support, DHCP relay, Port Security, dynamic ARP protection, Dynamic VLAN Support (GVRP), static routing, Generic VLAN Registration Protocol (GVRP), cloud managed, metal housing, Storm Control, IP source guard, TCP/UDP port setting, Voice VLAN, Private VLAN Edge (PVE), Guest VLAN, ARP spoofing, cable length detection, 2 redundant fans, ACL support, LED status indicators, LACP, secure remote management |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.3ac, IEEE 802.1s, IEEE 802.1ad, IEEE 802.1v, IEEE 802.1ab (LLDP), IEEE 802.1ak, IEEE 802.3at, IEEE 802.3az, IEEE 802.1AX, IEEE 802.1Qbb, IEEE 802.1Qat, IEEE 802.3bj, IEEE 802.1Qav, IEEE 802.3bt Type 4, Wi-Fi CERTIFIED 6E |
| Status Indicators | System, PoE, fan, stack, link, activity |
| Expansion / Connectivity | |
| Interfaces | 24 x 100/1000/2.5G RJ-45 PoE++ - 90 W ¦ 4 x 10Gbit LAN SFP+ ¦ 2 x 40Gbit LAN QSFP+ ¦ 1 x console RJ-45 ¦ 1 x USB Type A ¦ 1 x console (micro-USB) Type B |
| Expansion Slots | 1 (total) / 1 (free) x System Power Supply Unit (PSU) |
| Power | |
| Power Device | Internal power supply - hot-plug |
| Voltage Required | AC 100-240 V (50 - 60 Hz) |
| Power Consumption Operational | 720 Watt |
| Power Consumption Stand by | 80 Watt |
| Miscellaneous | |
| Included Accessories | Mounting brackets, slide rail kit |
| Cables Included | 1 x serial cable - 1.5 m ¦ 1 x micro-USB cable - 1 m |
| Rack Mounting Kit | Included |
| Compliant Standards | IC, FCC, WEEE, ACMA |
| Software / System Requirements | |
| OS Required | LCOS SX 5.20 |
| Dimensions & Weight | |
| Width | 44.2 cm |
| Depth | 37.5 cm |
| Height | 4.4 cm |
| Weight | 5.5 kg |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 10 years |
| Environmental Parameters | |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 40 °C |
| Humidity Range Operating | 10 - 90% (non-condensing) |
| Min Storage Temperature | 0 °C |
| Max Storage Temperature | 50 °C |
Features - Lancom Systems - 61883
General
24-Port
More Details
Product Code
04:432426
EAN Code
4044144618833
Manufacturer
Lancom Systems
