LevelOne FCS-3087 / Network surveillance camera / dome / outdoor / vandal / weatherproof / colour (Day&Night) / 5 MP / 2560 x 1920 / fixed focal / audio / LAN 10/100 / MJPEG, H.264 / DC 12 V / PoE | FCS-3087
FCS-3087
Find similar
Delivery
Payment options
Please sign in so that we can notify you about a reply
The LevelOne FCS-3087 Fixed Dome Outdoor Camera offers a highly reliable, cost-effective outdoor IP surveillance solution in a low-profile dome mounted casing, which is rated at IP66 and able to withstand outdoor operating conditions such as rain, snow, extreme heat, dust and humidity. The FCS-3087 offers 5-Megapixel resolution, and with 802.3af standard PoE, can use a single Cat.5 cable to run both power and data, making deployments easy and flexible. The dome mounting prevents malicious tampering with the camera, making it a secure and smart choice for all outdoor installations.
Special Features
- High-definition resolution
- Built-in infrared LEDs for night viewing
- Removable IR-cut filter for day and night surveillance
- Free video surveillance and CMS (Central Management System) software
Product Specification
| Device Type | Network surveillance camera |
| Audio Support | Yes: two-way audio capability |
| Form Factor | Dome |
| Camera Mount Type | Wall mount, ceiling mount |
| Connectivity Technology | Wired |
| Width | 11.1 cm |
| Depth | 11.1 cm |
| Height | 8.2 cm |
| Camera | Camera |
| Type | Colour - Day&Night - fixed - outdoor - vandal / weatherproof |
| Digital Video Format | MJPEG, H.264 |
| Max Digital Video Resolution | 2560 x 1920 |
| Motion Detection | Yes |
| Exposure Range | 1/3 sec - 1/10000 sec |
| Minimum Illumination | 0.01 lux F1.2 - AGC on ¦ 0 lux - IR |
| Infrared LEDs | Yes |
| Infrared Distance | 30 m |
| Video Capture | 2560 x 1920 @ 20 fps ¦ 2048 x 1536 @ 30 fps ¦ 1920 x 1080 @ 30 fps ¦ 1280 x 720 @ 30 fps |
| Features | Sharpness control, progressive scanning, saturation control, brightness control, Power over Ethernet, contrast control, Wide Dynamic Range (WDR), ONVIF support, Motion Detection Technology, infrared cut filter, reset button, microSD/SDHC/SDXC Memory Card slot |
| Image Sensor | Image Sensor |
| Type | 5 MP CMOS 1/3" |
| Lens Construction | Lens Construction |
| Type | Fixed focal |
| Focal Length | 4 mm |
| Horizontal Field of View (degree) | 83 |
| Interfaces | Interfaces |
| Network Interface | Ethernet 10Base-T/100Base-TX |
| Network Protocols | DDNS, DHCP, DNS, FTP, HTTP, NTP, SMTP, TCP/IP, UDP/IP, ICMP, SNMP, RTSP, RTP, HTTPS, UPnP, IPv6, Bonjour, RTCP, PPPoE, IGMP, QOS |
| Alarm Inputs Qty | 1 |
| Alarm Outputs Qty | 1 |
| Expansion / Connectivity | Expansion / Connectivity |
| Ports | LAN/power - RJ-45 ¦ Audio line in ¦ Audio line out |
| Supported Memory Cards | microSD Card, microSDHC Card, microSDXC Card |
| Miscellaneous | Miscellaneous |
| Included Accessories | Mounting kit |
| Compliant Standards | FCC, RoHS, IK10, IP66 |
| Power | Power |
| Power Requirements | DC 12 V / PoE |
| Power Device | 5 Watt |
| Software / System Requirements | Software / System Requirements |
| Software Included | Drivers & Utilities |
| OS Required | Microsoft Windows Vista / XP / 7 / 8 |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | -30 °C |
| Max Operating Temperature | 60 °C |
| Relative Humidity (operating) | 0 - 95% (non-condensing) |
