LevelOne FEP-1601W120 / Switch / 16 x 10/100 (PoE+) / desktop, rack-mountable / PoE+ (112 W) | FEP-1601W120
Please sign in so that we can notify you about a reply
Special Features
- IEEE 802.3x flow control protects against lost packets for reliable data transmission
- Auto-negotiation, auto-MDI/MDIX
- PoE on/off control per port by dip switches
- Metal housing
Product Specification
| Device Type | Switch - 16 ports |
| Enclosure Type | Desktop, rack-mountable |
| Subtype | Fast Ethernet |
| Ports | 16 x 10/100 (PoE+) |
| Power Over Ethernet (PoE) | PoE+ |
| PoE Budget | 112 W |
| Performance | Backplane speed: 3.2 Gbps ¦ Forwarding performance: 148000 packets per second |
| MAC Address Table Size | 4K entries |
| Features | Flow control, auto-negotiation, auto-uplink (auto MDI/MDI-X), half duplex mode, full duplex mode, built-in DIP switch, metal housing, PoE overcurrent protection, PoE circuit sorting protection |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3af, IEEE 802.3x, IEEE 802.3at |
| Built-in Devices | Led panel |
| Status Indicators | Power, active, PoE, link/speed |
| Expansion / Connectivity | Expansion / Connectivity |
| Interfaces | 16 x 100Base-TX RJ-45 PoE+ |
| Power | Power |
| Power Device | Internal power supply |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Power Consumption Operational | 120 Watt |
| Miscellaneous | Miscellaneous |
| Compliant Standards | FCC, RoHS |
| Dimensions & Weight | Dimensions & Weight |
| Width | 48 cm |
| Depth | 11.8 cm |
| Height | 4.4 cm |
| Weight | 2.2 kg |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 45 °C |
| Humidity Range Operating | 10 - 90% (non-condensing) |
| Min Storage Temperature | -40 °C |
| Max Storage Temperature | 70 °C |
| Humidity Range Storage | 10 - 90% (non-condensing) |
Features - LevelOne - FEP-1601W120
General
16-Port
More Details
Product Code
04:225886
EAN Code
4015867199848
Manufacturer
LevelOne
