LevelOne IGC-0102 / Fibre media converter / GigE / 10Base-T, 100Base-TX, 1000Base-T, 1000Base-X / RJ-45 / SFP (mini-GBIC) | IGC-0102
Please sign in so that we can notify you about a reply
Special Features
- 10/100/1000Mbps wire speed transmission and reception
- 40°C to 75°C operating temperature range
- 6KV surge protection level on each port
- ESD and surge protection
- Supports DDMI SFP transceiver
- Supports DIN-rail installation
Product Specification
| Device Type | Fibre media converter |
| Form Factor | DIN rail mountable |
| Colour | Black |
| Networking | Networking |
| Connectivity Technology | Wired |
| Cabling Type | 10Base-T, 100Base-TX, 1000Base-T, 1000Base-X |
| Data Link Protocol | 10Mb LAN, 100Mb LAN, GigE |
| Status Indicators | Power, alarm, link/activity |
| Features | Digital Diagnostics Monitoring Interface (DDMI), metal housing, 6KV Surge protection, 8KV ESD Protector (air-gap discharge), 6KV ESD Protector (contact discharge) |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.3ab |
| Expansion / Connectivity | Expansion / Connectivity |
| Interfaces | 1 x Ethernet 10Base-T/100Base-TX/1000Base-T - RJ-45 female ¦ 1 x Ethernet 1000Base-X - SFP ¦ 1 x relay |
| Miscellaneous | Miscellaneous |
| Included Accessories | Power terminal block |
| Compliant Standards | FCC Part 15 B, EN 61000-4-2, EN 61000-4-5 |
| Power | Power |
| Installed Qty | 0 |
| Power Redundancy | Optional |
| Max Supported Qty | 2 |
| Voltage Required | DC 12 - 60 V |
| Power Consumption Operational | 5 Watt |
| Dimensions & Weight | Dimensions & Weight |
| Width | 10.1 cm |
| Depth | 6.5 cm |
| Height | 3.6 cm |
| Weight | 300 g |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | -40 °C |
| Max Operating Temperature | 75 °C |
| Humidity Range Operating | 0 - 95% (non-condensing) |
Features - LevelOne - IGC-0102
More Details
Product Code
04:374004
EAN Code
4015867223949
Manufacturer
LevelOne
