LevelOne IGP-1061 / Switch / -40°C to 75°C / Managed / 2 x 10/100/1000 (PoE++) + 6 x 10/100/1000 (PoE+) + 2 x Gigabit SFP / desktop, DIN rail mountable, wall-mountable / PoE++ (360 W) / DC power | IGP-1061
Please sign in so that we can notify you about a reply
Product Specification
| Device Type | Switch - 10 ports - Managed |
| Enclosure Type | Desktop, DIN rail mountable, wall-mountable |
| Subtype | Gigabit Ethernet |
| Ports | 2 x 10/100/1000 (PoE++) + 6 x 10/100/1000 (PoE+) + 2 x Gigabit SFP |
| Power Over Ethernet (PoE) | PoE++ |
| PoE Budget | 360 W |
| Performance | Backplane speed: 20 Gbps |
| MAC Address Table Size | 8K entries |
| Jumbo Frame Support | 10KB |
| Remote Management Protocol | SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTPS, SSH, SMTP |
| Encryption Algorithm | TLS 1.0, SSL 3.0, SSL 2.0 |
| Authentication Method | Secure Shell (SSH), RADIUS, TACACS+, Secure Shell v.2 (SSH2) |
| Features | Auto-uplink (auto MDI/MDI-X), half duplex mode, full duplex mode, fanless, metal housing, SNMP support, Ethernet Ring Protection Switching (ERPS), Protocol-based VLANs support, 6KV Surge protection, Device Management System (DMS), MAC based VLAN, Rapid Reconfiguration of Spanning Tree (RSTP), 8KV ESD Protector (contact discharge), 15KV ESD Protector (air-gap discharge) |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3x, IEEE 802.3at, IEEE 802.3bt |
| Processor | RTL8380M |
| RAM | 1 GB |
| Flash Memory | 128 MB |
| Status Indicators | Power, link/activity |
| Expansion / Connectivity | Expansion / Connectivity |
| Interfaces | 2 x 1000Base-T RJ-45 PoE++ - 90 W ¦ 2 x Gigabit LAN SFP ¦ 6 x 1000Base-T RJ-25 PoE+ - 30 W |
| Power | Power |
| Voltage Required | DC 48 - 57 V |
| Miscellaneous | Miscellaneous |
| Colour | Black |
| Included Accessories | DIN-rail mounting kit, power terminal block |
| MTBF | 338,634 hours |
| Compliant Standards | EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, EN 61000-4-5, FCC, IEC 60068-2-27, IEC 60068-2-32, IEC 60068-2-6, EMI, IP30 |
| Dimensions & Weight | Dimensions & Weight |
| Width | 16.5 cm |
| Depth | 11.5 cm |
| Height | 5 cm |
| Weight | 500 g |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | -40 °C |
| Max Operating Temperature | 75 °C |
| Humidity Range Operating | 95% |
| Min Storage Temperature | -40 °C |
| Max Storage Temperature | 85 °C |
Features - LevelOne - IGP-1061
More Details
Product Code
04:401920
EAN Code
4015867227886
Manufacturer
LevelOne
