LevelOne NVR-1209 / NVR / 9 channels / networked | NVR-1209
Please sign in so that we can notify you about a reply
Special Features
- HDMI local display - different display mode according to number of channels
- Support H.264 compression
- Recording 10 MP resolution
- Display - up to 4-Megapixel (local display), up to 10-Megapixel (remote display)
- Recording throughput - 30 fps per channel - 270fps total per model
- Support - scheduled recording, event recording, event speed-up recording
- 2-bay desktop - 3.5 inch serial ATA - support 8 TB total
- Live view local 9 channels, remote 9 channels. synchronized playback local 9 channels
- Export snapshot, video with RAW and AVI formats
- Event trigger, response and notification
- Remote viewing by mobile client, web client
- Multi-language support
Product Specification
| Device Type | NVR |
| Video Channels | 9 |
| IP Cameras Supported | 9 |
| Compression Format | G.711, H.264, PCM, AVI |
| Package Content | DVR, external power adapter, mouse |
| OS Provided | Linux |
| Software Included (Y) | Drivers & Utilities |
| Compliant Standards | EN55024, EN55022 Class B, FCC Part 15 B |
| Security DVR | Security DVR |
| Frame Rate (Record) | 30 fps, 270 fps |
| Display Modes | 9 split screens |
| Record Events | Alarm, motion detection, event |
| Networked | Yes |
| Features | Pan/Tilt/Zoom support, e-mail alarm notifications |
| Hard Drive | Hard Drive |
| Quantity Supported | 2 |
| Interface | Serial ATA |
| Removable | Yes |
| Supported Max Total Capacity | 8 TB |
| Networking | Networking |
| Network Interfaces | Ethernet 10Base-T/100Base-TX/1000Base-T |
| Supported Protocols | HTTP |
| Features | Reset button |
| System Requirements | System Requirements |
| Browser | Internet Explorer 9 or later |
| Connections | Connections |
| Video Output Ports | HDMI x 1 |
| Network Port | 10/100/1000Base-T x 2 |
| Other Ports | USB 2.0 x 2 |
| Power | Power |
| Voltage | 120 / 230 V |
| Power Consumption | 22 Watt |
| Dimensions & Weight | Dimensions & Weight |
| Width | 13.5 cm |
| Depth | 25.1 cm |
| Height | 12.1 cm |
| Weight | 1.32 kg |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 40 °C |
| Humidity Range Operating | 10 - 85% |
Features - LevelOne - NVR-1209
More Details
Product Code
04:157274
EAN Code
4015867190760
Manufacturer
LevelOne
