LogiLink USB Line Extender / USB extender / USB / up to 60 m | UA0021D
Description
The LogiLink USB Line Extender is an extender between USB device and host computer with embedded into connector "intelligent" integrated circuits on both sides of the extender. The USB extender with the chip inside is not a passive extender. It is an active device. The USB signals going in and out of this extender in both directions are buffered to assure signal quality. Unlike passive USB extender the IC prevents signal degradation. The embedded "intelligent" integrated circuit cleans, amplifies USB signal and watches USB 1.1 protocol. Its control state machine enables and disables USB and cable transmitters inside the chip depending on USB signals.
LogiLink USB Line Extender / USB extender | UA0021D
Special Features
- Fully compliant with USB 1.1 specification
- Provides support for any full-speed or low-speed USB devices
- Allows a USB device to have its cable length extended up to 198 feet
- Embedded USB 1.1 transceivers prevents signal loss
- Low cost in comparison with extension of cable using hubs or other USB extender
- No software driver required
Product Specification
| Device Type | USB extender |
| Form Factor | External |
| Connectivity Technology | Wired |
| Data Link Protocol | USB |
| Max Transfer Distance | 60 m |
| Compliant Standards | USB 1.1 |
| Interfaces | 1 x USB - Type A female ¦ 1 x USB - Type A male |
| Cables Included | 1 x USB cable - 30 cm |
| Compliant Standards | RoHS |
Features - LogiLink - UA0021D
Length
>50m
More Details
Product Code
04:96899
EAN Code
4260113567487
Manufacturer
LogiLink
