LogiLink - Video/audio/infrared extender - HDMI, infrared - up to 70 m | HD0030
HD0030
Find similar
Delivery
Payment options
Please sign in so that we can notify you about a reply
Special Fetures
- Based on Ethernet technology over a single CAT 5e/6/7/8 cable
- Bandwidth: 6.0 Gbit/s at 600 MHz per channel (18 Gbit/s total)
- Supports Ultra HD A/V signal transmission up to 70 m/229 ft
- Supports UHD 4K/60 Hz YUV 4:4:4 and Full 3D
- Power supply unit: DC 12 V/1 A
- Supports HDMI Loop Out, EDID bypass, bidirectional IR function (broadband 20 - 60 KHz) and PoC (12 V)
- Compliant with HDCP 2.2/1.4
- Supports DDC and HDR10
- Support uncompressed audio such as LPCM7.1
- Support compressed audio such as DTS, Dolby Digital
- Metal chassis, mountable
- Plug-and-play - no driver installation needed
Product Specification
| Device Type | Video/audio/infrared extender |
| Form Factor | External |
| Networking | |
| Connectivity Technology | Wired |
| Data Link Protocol | HDMI, infrared |
| Data Transfer Rate | 18 Gbps |
| Max Resolution | 4K @ 60 Hz |
| Max Video Bandwidth | 600 MHz |
| Max Transfer Distance | 70 m |
| Features | HDCP compliant, 3D support, 4K resolution support, metal housing, 720p resolution support, power over cable (PoC), LPCM 7.1 support, Dolby TrueHD support, DTS-HD Master Audio support, 1080p resolution support, DTS support, 1080i resolution support, Dolby Digital support, Cat 5e, HDR10 support, Cat 6 |
| Compliant Standards | HDCP 1.4, HDCP 2.2 |
| Expansion / Connectivity | |
| Interfaces | 2 x HDMI (transmitter) - 19 pin HDMI Type A female ¦ 1 x IR (transmitter) - mini jack female ¦ 1 x HDMI (receiver) - 19 pin HDMI Type A female ¦ 1 x IR (receiver) - mini jack female |
| Miscellaneous | |
| Compliant Standards | Plug and Play, DDC, HDCP 2.2, HDCP 1.4 |
| Power | |
| Power Device | External power adapter |
| Installed Qty | 1 |
| Voltage Required | AC 100-240 V (50/60 Hz) |
| Dimensions & Weight | |
| Dimensions (WxDxH) / Weight Details | Transmitter: 10 cm x 8.8 cm x 2.3 cm / 200 g ¦ Receiver: 10 cm x 8.8 cm x 2.3 cm / 200 g |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 24.3 cm |
| Shipping Depth | 19.6 cm |
| Shipping Height | 6 cm |
| Shipping Weight | 730 g |
| Environmental Parameters | |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 70 °C |
| Humidity Range Operating | 10 - 85% (non-condensing) |
Features - LogiLink - HD0030
Length
>50m
More Details
Product Code
04:381239
EAN Code
4052792050769
Manufacturer
LogiLink
No posts found
