MikroTik Cloud Router Switch CRS326-24S+2Q+RM / Switch / L3 / Managed / 24 x 10 Gigabit SFP+ + 2 x 40 Gigabit QSFP+ / rack-mountable / AC 100 / 240 V | CRS326-24S+2Q+RM
Please sign in so that we can notify you about a reply
Product Specification
| Device Type | Switch - 26 ports - L3 - Managed |
| Enclosure Type | Rack-mountable 1U |
| Subtype | 40 Gigabit Ethernet |
| Ports | 24 x 10 Gigabit SFP+ + 2 x 40 Gigabit QSFP+ |
| Performance | Non-blocking switching capacity: 320 Gbps ¦ Switching capacity: 640 Gbps ¦ Forwarding rate: 252 Mpps |
| Features | Reset button |
| Processor | 1 QCA9531: 650 MHz |
| RAM | 64 MB |
| Flash Memory | 16 MB |
| Status Indicators | Link/activity, fault, user, power 1, power 2 |
| Expansion / Connectivity | Expansion / Connectivity |
| Interfaces | 1 x serial (console) RJ-45 ¦ 1 x management (LAN) RJ-45 ¦ 2 x 40GBase-X QSFP+ ¦ 24 x 10Gbit LAN SFP+ ¦ 1 x USB Type A |
| Power | Power |
| Power Device | Internal power supply |
| Installed Qty | 2 |
| Max Supported Qty | 2 |
| Power Redundancy | Yes |
| Power Redundancy Scheme | 1+1 |
| Voltage Required | AC 100 - 240 V |
| Power Consumption Operational | 69 Watt |
| Miscellaneous | Miscellaneous |
| Included Accessories | Feet set, mounting screws, 2 x power cords, 2 rack mounting ears |
| Rack Mounting Kit | Included |
| Software / System Requirements | Software / System Requirements |
| Software Included | MikroTik SwitchOS/RouterOS (licence level 5) |
| Dimensions & Weight | Dimensions & Weight |
| Width | 44.3 cm |
| Depth | 18.3 cm |
| Height | 4.4 cm |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | -20 °C |
| Max Operating Temperature | 60 °C |
Features - MikroTik - CRS326-24S+2Q+RM
General
24-Port
More Details
Product Code
07:229905
EAN Code
4752224002211
Manufacturer
MikroTik
