ZOTAC ZBOX MAGNUS ONE ERP74070SW / Barebone / mini PC 1 x Core i7 i7-14700 / up to 5.4 GHz / RAM 0 GB / SSD 1 TB / NVMe / GeForce RTX 4070 Super / Gigabit Ethernet, 2.5 Gigabit Ethernet, IEEE 802.11ax (Wi-Fi 6), Bluetooth 5.2 / W | ZBOX-ERP74070SW-BE-W5B
Please sign in so that we can notify you about a reply
Product Features
- Powerful processing capabilities
The ZOTAC ZBOX MAGNUS ONE is powered by an Intel Core i7-14700 processor featuring 20 cores. This allows for high processing performance, making it suitable for both gaming and professional applications. - Advanced graphics performance
Equipped with 12 GB of GDDR6 SDRAM and an NVIDIA GeForce RTX 4070 SUPER graphics processor, the system offers graphics performance and supports high-resolution displays. - Extensive connectivity options
The mini PC provides multiple port options including HDMI, DisplayPort, USB 3.0 and USB 3.1, along with Thunderbolt 4 for versatile connectivity to peripherals and external displays. - Enhanced networking capabilities
With support for dual 2.5 Gigabit Ethernet ports and wireless protocols including Wi-Fi 6 and Bluetooth 5.2, the ZBOX MAGNUS ONE ensures fast and reliable network connections. - Efficient power management
The system features an 80 PLUS Platinum-rated power supply that delivers 500 watts, ensuring power delivery while maintaining low energy consumption.
Special Features
- Compact mini PC design for space-saving setups
- Powerful Intel Core i7 processor for high-performance computing
- High-end NVIDIA GeForce RTX graphics for visual output
- Versatile connectivity options including Thunderbolt 4 and multiple USB ports
- Advanced networking features with dual 2.5 Gigabit Ethernet and Wi-Fi 6 support
Product Specification
| Type | PC barebone |
| Product Form Factor | Mini PC |
| Processor / Chipset | Processor / Chipset |
| CPU | Intel Core i7 (14th Gen) i7-14700 |
| Clock Speed | 2.1 GHz (P-core) / 1.5 GHz (E-core) |
| Max Turbo Speed | 5.4 GHz (P-core) / 4.2 GHz (E-core) |
| Number of Cores | 20-core |
| CPU Qty | 1 |
| Max CPU Qty | 1 |
| L2 cache | 28 MB |
| Processor Main Features | Intel Smart Cache |
| Cache Memory | Cache Memory |
| Installed Size | 33 MB |
| Cache Per Processor | 33 MB |
| RAM | RAM |
| Installed Size | 0 GB (installed) / 64 GB (max) |
| Technology | DDR5 SDRAM |
| Form Factor | SO-DIMM 262-pin |
| Slots | 2 (Total) / 2 (empty) |
| Hard Drive | Hard Drive |
| Type | SSD - M.2 |
| Capacity | 1 x 1 TB |
| Interface Type | PCI Express 4.0 x4 |
| Features | NVM Express (NVMe) |
| Storage Controller | Storage Controller |
| Type | 1 x SATA |
| Controller Interface Type | SATA 6Gb/s |
| Optical Storage | Optical Storage |
| Type | No optical drive |
| Card Reader | Card Reader |
| Type | 3 in 1 card reader |
| Supported Flash Memory Cards | SD Memory Card, SDHC Memory Card, SDXC Memory Card |
| Monitor | Monitor |
| Monitor Type | None. |
| Graphics Controller | Graphics Controller |
| Graphics Processor | NVIDIA GeForce RTX 4070 SUPER |
| Video Memory | 12 GB GDDR6 SDRAM |
| Video Interfaces | HDMI, DisplayPort |
| Audio Output | Audio Output |
| Sound Output Mode | 7.1 channel surround |
| Networking | Networking |
| Ethernet Ports | 2 x 2.5 Gigabit Ethernet |
| Wireless LAN Supported | Yes |
| Data Link Protocol | Ethernet, Gigabit Ethernet, Fast Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, 2.5 Gigabit Ethernet, IEEE 802.11ax (Wi-Fi 6), Bluetooth 5.2 |
| Expansion / Connectivity | Expansion / Connectivity |
| Bays | 1 (total) / 1 (free) x internal 2.5" |
| Slots | 1 (total) / 1 (free) x M.2 Card - 2242/2280 1 (total) / 1 (free) x M.2 Card - 2242/2280/22110 |
| Interfaces | 3 x DisplayPort 2 x HDMI 2 x LAN (2.5Gigabit Ethernet) 4 x USB 3.1 1 x USB-C 3.0 1 x headphones/microphone 3 x USB 3.0 1 x Thunderbolt 4 |
| Miscellaneous | Miscellaneous |
| Included Accessories | 2x wireless aerials, USB flash drive |
| Theft/Intrusion Protection | Security lock slot (cable lock sold separately) |
| Security Slot Type | Kensington security slot |
| Power | Power |
| Device Type | Power supply |
| Power Provided | 500 Watt |
| 80 PLUS Certification | 80 PLUS Platinum |
| Operating System / Software | Operating System / Software |
| OS Provided | Windows 11 Home |
| Dimensions & Weight | Dimensions & Weight |
| Width | 12.6 cm |
| Depth | 26.55 cm |
| Height | 24.9 cm |
| Dimensions & Weight (Shipping) | Dimensions & Weight (Shipping) |
| Shipping Width | 32.7 cm |
| Shipping Depth | 44 cm |
| Shipping Height | 20.5 cm |
Features - ZOTAC - ZBOX-ERP74070SW-BE-W5B
CPU Type
- Intel Core i7
Capacity
1TB
More Details
Product Code
03:253334
EAN Code
4895173629808
Manufacturer
ZOTAC
