Zebra LI2208 / Barcode scanner / handheld / linear imager / 547 scan / sec / decoded / USB | LI2208-SR7U2100SGW
Product Features
- Advanced 1-D scanning
Get the next evolution in 1-D bar code scanning and improve productivity in your operations with LI2208. Virtually any 1-D bar code can be captured - including the typical bar codes that are printed on paper labels, and electronic bar codes displayed on the screen of a mobile phone, tablet or computer - that allows retailers to easily process loyalty cards, mobile coupons and more. A patented optical design achieves an industry leading working range. Since bar codes can be captured at extreme angles, scanning is easier than ever, so workers spend less time maneuvering the scanner and more time on task. - Improve productivity
The LI2208 performance and design features combine to allow your workers to better meet the needs of your business and your customers. Workers can scan more types of bar codes on more types of surfaces, increasing productivity at the retail Point of Sale (POS), in the warehouse, on the production line in a light industrial manufacturing plant, at event registration, hotel check-in and more. - Built for all-day everyday use
A patented single circuit board improves reliability by eliminating connectors and ribbon cables, which are the most common points of failure. You can drop it and use it in dusty and damp environments - and still expect reliable operation. - Superior out-of-box experience
Smart auto-host detect cables automatically distinguish which interface is attached, reducing the need to scan multiple parameter bar codes. Over 90 international keyboards are hosted within the scanner making localized set up fast and easy.
Special Features
- Advanced 1-D scanning
- Improve productivity
- Built for all-day everyday use
- Superior out-of-box experience
Product Specification
Type | Barcode scanner - handheld |
Colour | Twilight black |
Localisation | Worldwide |
Barcode | Barcode |
Interface Type | USB |
Minimum Bar Width | 3 mil |
Scan Field Width | 2.5 cm - 78.7 cm |
Scan Element Type | Linear imager |
Light Source Wave Length | 617 nm |
Scan Mode | Single-pass |
Scan Speed | 547 scan / sec |
Max Working Distance | 6 m |
Skew (Degrees) | 65 |
Pitch (Degrees) | 65 |
Print Contrast Signal (PCS) | 15% |
Decode Capability | EAN/JAN, Code 93, Matrix 2 of 5, Code 39, UCC/EAN-128, ISBT 128, NW-7, ISBN, GS1 DataBar, Bookland, Code 32, Code 39 Full ASCII, EAN/JAN-8, EAN/JAN-13, UPC-A, UPC-E, Discrete 2 of 5, Italy Pharmacode, Codabar, Code 128, Code 11, UPC, Interleaved 2 of 5, ITF, IATA 2 of 5, UPC-E1, GS1 DataBar-14, Code 39 Trioptic, GS1 DataBar Expanded, GS1 DataBar Limited |
TTL Decoding | Decoded |
Connectivity Technology | Wired |
Expansion / Connectivity | Expansion / Connectivity |
Interfaces | 1 x USB - Type A |
Miscellaneous | Miscellaneous |
Included Accessories | Stand |
Cables Included | 1 x USB cable - 2.1 m |
Compliant Standards | IEC 60601-1-2, ICES-003 Class B, FCC Part 15 B, RoHS, UL 60950-1, IEC 60950-1, EN 60950-1, CSA C22.2 No. 60950-1, IP42 |
Power | Power |
Electric Current Required | 40 mA (standby), 165 mA (operating) |
Software | Software |
Software Included | Drivers & Utilities |
Dimensions & Weight | Dimensions & Weight |
Width | 9.9 cm |
Depth | 16 cm |
Height | 6.7 cm |
Weight | 140 g |
Manufacturer Warranty | Manufacturer Warranty |
Service & Support | Limited warranty - 5 years |
Environmental Parameters | Environmental Parameters |
Min Operating Temperature | 0 °C |
Max Operating Temperature | 50 °C |
Humidity Range Operating | 5 - 95% (non-condensing) |
Drop Specification | 1.8 m to concrete |
