NETGEAR ProSafe AXM761 / SFP+ transceiver module / 10 GigE / 10GBase-SR / LC multi-mode / up to 300 m / 850 nm (pack of 10) | AXM761P10-10000S
Please sign in so that we can notify you about a reply
Product Specification
| Packaged Quantity | 10 (specifications are for single item) |
| Device Type | SFP+ transceiver module |
| Form Factor | Plug-in module |
| Networking | Networking |
| Connectivity Technology | Wired |
| Cabling Type | 10GBase-SR |
| Data Link Protocol | 10 GigE |
| Data Transfer Rate | 10 Gbps |
| Optical Wave Length | 850 nm |
| Max Transfer Distance | 300 m |
| Compliant Standards | IEEE 802.3ae |
| Expansion / Connectivity | Expansion / Connectivity |
| Interfaces | 1 x Ethernet 10GBase-SR - LC multi-mode x 2 |
| Compatible Slots | 1 x SFP+ |
| Miscellaneous | Miscellaneous |
| MTBF | 4,986,536 hours |
| Compliant Standards | UL 1950, CSA 22.2 No. 950, RoHS |
| Dimensions & Weight | Dimensions & Weight |
| Width | 1.37 cm |
| Depth | 5.57 cm |
| Height | 1.19 cm |
| Weight | 17.1 g |
| Manufacturer Warranty | Manufacturer Warranty |
| Service & Support | Limited warranty - 5 years |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 70 °C |
Features - NetGear - AXM761P10-10000S
More Details
Product Code
07:643148
EAN Code
0606449087840
Manufacturer
NetGear
