NETGEAR GS324P / Switch / unmanaged / 16 x 10/100/1000 (PoE+) + 8 x 10/100/1000 / desktop, rack-mountable / PoE+ (190 W) | GS324P-100EUS
Please sign in so that we can notify you about a reply
Special Features
- Energy-efficient technology for power savings
- Auto-MDI/MDIX eliminates the need for crossover cables
- Non-blocking switching architecture for maximum throughput at wire speed
- Auto-negotiation for automatic connection at the highest common speed between switch and an end device
- Power-over-Ethernet (PoE) option available for powering IP Security Cameras, VoIP phones, wireless access points, and other PD-powered devices
- Fanless design for silent operation
Product Specification
| Device Type | Switch - 24 ports - unmanaged |
| Enclosure Type | Desktop, rack-mountable |
| Subtype | Gigabit Ethernet |
| Ports | 16 x 10/100/1000 (PoE+) + 8 x 10/100/1000 |
| Power Over Ethernet (PoE) | PoE+ |
| PoE Budget | 190 W |
| Performance | Non-blocking bandwidth: 48 Gbps ¦ Packet buffer size: 192 KB ¦ Forwarding performance (64-byte packet size): 1448000 pps ¦ Latency (64-byte packets): 4 µs |
| MAC Address Table Size | 8K entries |
| Jumbo Frame Support | 10000 bytes |
| Features | Auto-negotiation, auto-uplink (auto MDI/MDI-X), DiffServ support, half duplex mode, full duplex mode, Energy Efficient Ethernet, Class of Service (CoS), 1 fan, Weighted Round Robin (WRR) |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3at, IEEE 802.3az |
| Status Indicators | Power, PoE, fan, link/activity/speed |
| Expansion / Connectivity | Expansion / Connectivity |
| Interfaces | 16 x 1000Base-T RJ-45 PoE+ - 30 W ¦ 8 x 1000Base-T RJ-45 |
| Power | Power |
| Power Device | Internal power supply |
| Installed Qty | 1 |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Power Consumption Operational | 210 Watt |
| Power Consumption Stand by | 10 Watt |
| Miscellaneous | Miscellaneous |
| Included Accessories | Rubber feet |
| Rack Mounting Kit | Included |
| MTBF | 1,193,574 hours |
| Compliant Standards | UL, VCCI, CB, IC Class A, FCC Part 15 A, LVD, KC, RCM |
| Localisation | United Kingdom, Europe |
| Dimensions & Weight | Dimensions & Weight |
| Width | 33 cm |
| Depth | 20.6 cm |
| Height | 4.3 cm |
| Weight | 2.44 kg |
| Manufacturer Warranty | Manufacturer Warranty |
| Service & Support | Limited warranty - 3 years ¦ Limited warranty - phone consulting - 90 days |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 45 °C |
| Humidity Range Operating | 10 - 90% (non-condensing) |
| Min Storage Temperature | -20 °C |
| Max Storage Temperature | 70 °C |
| Humidity Range Storage | 10 - 95% (non-condensing) |
Features - NetGear - GS324P-100EUS
General
16-Port
More Details
Product Code
0714640
EAN Code
0606449144802
Manufacturer
NetGear
