NETGEAR Smart MS510TXM / Switch / L3 Lite / smart / 4 x 100/1000/2.5G + 4 x 1/2.5/5/10GBase-T + 2 x 10 Gigabit SFP+ (uplink) / desktop, rack-mountable | MS510TXM-100EUS
Please sign in so that we can notify you about a reply
Special Features
- Connect your WAX610PA with MS510TXM
- Manage all devices from a single dashboard with NETGEAR Insight Powerful Connectivity and Security
- Advanced VLAN support for better network segmentation
- L2/L3/L4 access control lists (ACLs) for granular network access control including 802.1x port authentication
- Advanced per port PoE controls for remote power management of PoE powered devices including operation scheduling
- Advanced QoS (Quality of Service) for traffic prioritization including portbased, 802.1p and L2/L3/L4 DSCPbased
- Auto "denial-of-service" (DoS) prevention
- IGMP Snooping and Querier for multicast optimization
- Egress Rate limiting and priority queuing for better bandwidth allocation
- Port mirroring for network monitoring
- Energy Efficient Ethernet (IEEE 802.3az) for maximum power savings
- IPv6 management: IPv6 QoS, IPv6 ACL, IPv6 Multicast, and static and dynamic IPv6 address assignment
- Cable test to troubleshoot connection issues
- Easy-to-use Web browser-based management GUI available in English, German and Japanese
- SNMP v1, v2c, v3 and RMON remote monitoring
Product Specification
| Device Type | Switch - 8 ports - L3 Lite - smart |
| Enclosure Type | Desktop, rack-mountable |
| Ports | 4 x 100/1000/2.5G + 4 x 1/2.5/5/10GBase-T + 2 x 10 Gigabit SFP+ (uplink) |
| Performance | Fabric throughput: 140 Gbps ¦ Forwarding rate (64-byte packets): 14.8 Mpps ¦ 2.5 Gbps copper latency (64-byte packets): 5.903 µs ¦ 2.5 Gbps copper latency (1518-byte packets): 6.040 µs ¦ 2.5 Gbps copper latency (9216-byte packets): 6.079 µs ¦ 10 Gbps copper latency (64-byte packets): 2.420 µs ¦ 10 Gbps copper latency (1518-byte packets): 2.501 µs ¦ 10 Gbps copper latency (9216-byte packets): 2.499 µs ¦ 10 Gbps fibre latency (64-byte packets): 1.257 µs ¦ 10 Gbps fibre latency (1518-byte packets): 1.337 µs ¦ 10 Gbps fibre latency (9216-byte packets): 1.348 µs |
| Capacity | Packet buffer size: 2 MB ¦ ACL entries (ingress): 100 ¦ VLANs supported: 256 ¦ IGMP groups: 256 ¦ Priority queues: 8 ¦ DHCP snooping entries: 256 |
| MAC Address Table Size | 32000 entries |
| Jumbo Frame Support | 10KB |
| Routing Protocol | IGMPv2, IGMP, IGMPv3, MLDv2, MLD, MSTP, RSTP, STP |
| Remote Management Protocol | SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, SNMP 3, SNMP 2c, HTTP, HTTPS, IPv6, RSTP, TACACS+, RADIUS |
| Encryption Algorithm | TLS 1.2 |
| Authentication Method | RADIUS, TACACS+, Extensible Authentication Protocol (EAP) |
| Features | Flow control, IGMP snooping, Syslog support, DoS attack prevention, port mirroring, DiffServ support, store and forward, Broadcast Storm Control, full duplex mode, Multicast Storm Control, Unicast Storm Control, firmware upgradable, SNTP support, DHCP snooping, Access Control List (ACL) support, LLDP support, Link Aggregation Control Protocol (LACP), DHCP client, Dynamic VLAN Support (GVRP), dual firmware images, loop prevention, Strict Priority (SP), 802.1x authentication, cloud managed, VoIP support, DiffServ Code Point (DSCP) support, 2 fans, cable test, Bridge protocol data unit (BPDU), IGMP querier, DNS client, Voice VLAN, LLDP-MED, Guest VLAN, User Datagram Protocol (UDP), protected ports, Zero-touch provisioning (ZTP), Energy-Efficient Ethernet (EEE), Weighted Round Robin (WRR), loopback detection, egress rate limiting, block unknown multicast, Advanced QoS, Unknown Storm Control, Extensible Authentication Protocol over LAN (EAPOL) |
| Compliant Standards | IEEE 802.1D, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3az, UPnP |
| Processor | : 1 GHz |
| RAM | 256 MB |
| Flash Memory | 64 MB |
| Status Indicators | Power, fan, link/activity/speed |
| Expansion / Connectivity | Expansion / Connectivity |
| Interfaces | 4 x 100/1000/2.5G RJ-45 ¦ 4 x 1/2.5/5/10GBase-T RJ-45 ¦ 2 x 10GBase-X SFP+ uplink |
| Power | Power |
| Power Device | Internal power supply |
| Installed Qty | 1 |
| Power Consumption Operational | 47 Watt |
| Miscellaneous | Miscellaneous |
| Included Accessories | Rubber feet |
| Rack Mounting Kit | Included |
| MTBF | 1,059,519 hours |
| Localisation | Europe |
| Dimensions & Weight | Dimensions & Weight |
| Width | 33 cm |
| Depth | 20.6 cm |
| Height | 4.3 cm |
| Weight | 2.08 kg |
| Manufacturer Warranty | Manufacturer Warranty |
| Service & Support | Limited warranty - replacement - lifetime - response time: next business day |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 50 °C |
| Humidity Range Operating | 90% (non-condensing) |
| Min Storage Temperature | -20 °C |
| Max Storage Temperature | 70 °C |
| Humidity Range Storage | 95% (non-condensing) |
Features - NetGear - MS510TXM-100EUS
General
8-Port
More Details
Product Code
CA66028
EAN Code
0606449152364
Manufacturer
NetGear
