NETGEAR Plus GS316EPP / Switch / Managed / 15 x 10/100/1000 (PoE+) + 1 x SFP / desktop, wall-mountable / PoE+ (231 W) | GS316EPP-100PES
Please sign in so that we can notify you about a reply
Product Features
- Gigabit Ethernet
16 ports provide up to 1000 Mbps of dedicated, non-blocking bandwidth each. - PoE+ support
15 PoE+ ports provide a total of 231W of power so you can power and connect your devices with a single wire. - Advanced PoE controls
Manage PoE prioritization, PoE power limit per port, PoE scheduling and more for simple control over all PoE-powered devices. - Non-blocking switching
10Gbps (10/100/1000 Mbps) line rate fabric ensures congestion-free connectivity to your devices. - Fanless design
Silent operation makes this switch perfect for noise-sensitive environments. - Versatile mounting options
Install your switch on your desktop, or mount it to your wall or rack with the hardware provided in the box.
Special Features
- Gigabit Ethernet
- PoE+ support
- Advanced PoE controls
- Non-blocking switching
- Fanless design
- Versatile mounting options
Product Specification
| Device Type | Switch - 16 ports - Managed |
| Enclosure Type | Desktop, wall-mountable |
| Subtype | Gigabit Ethernet |
| Ports | 15 x 10/100/1000 (PoE+) + 1 x SFP |
| Power Over Ethernet (PoE) | PoE+ |
| PoE Budget | 231 W |
| Performance | Bandwidth: 28 Gbps |
| Capacity | Buffer memory (kBytes): 192 ¦ VLANs supported: 64 ¦ Multicast groups: 128 |
| MAC Address Table Size | 4K entries |
| Jumbo Frame Support | 10000 bytes |
| Routing Protocol | IGMPv2, IGMP, IGMPv3 |
| Remote Management Protocol | HTTP, DHCP |
| Features | Flow control, VLAN support, IGMP snooping, port mirroring, store and forward, Broadcast Storm Control, full duplex mode, Quality of Service (QoS), fanless, DHCP client, loop prevention, Class of Service (CoS), Type of Service (ToS), DiffServ Code Point (DSCP) support, cable test, Link Aggregation, rate limit, Denial of Service (DoS) protection, Energy-Efficient Ethernet (EEE), Weighted Round Robin (WRR), loopback detection, VLAN Tagging, port-based VLAN, port trunking, block unknown multicast, password protection, PoE scheduling, uninterrupted PoE |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3at, IEEE 802.3az |
| Status Indicators | Power, system, PoE, link/activity/speed, PoE max |
| Expansion / Connectivity | Expansion / Connectivity |
| Interfaces | 15 x 1000Base-T RJ-45 PoE+ - 30 W ¦ 1 x 1000Base-X SFP |
| Power | Power |
| Power Device | External power adapter |
| Miscellaneous | Miscellaneous |
| Included Accessories | Rubber feet, wall mounting kit |
| MTBF | 570,435 hours |
| Compliant Standards | CSA, VCCI, BSMI, EN55024, KC, FCC Part 15 Class B, ACMA, EN 55032 |
| Dimensions & Weight | Dimensions & Weight |
| Width | 28.6 cm |
| Depth | 10.2 cm |
| Height | 2.7 cm |
| Weight | 883 g |
| Manufacturer Warranty | Manufacturer Warranty |
| Service & Support | Limited warranty - 5 years ¦ Limited warranty - power supply - 2 years ¦ Limited warranty - phone consulting - 90 days with product registration |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 40 °C |
| Humidity Range Operating | 90% (non-condensing) |
| Min Storage Temperature | -20 °C |
| Max Storage Temperature | 70 °C |
| Humidity Range Storage | 95% (non-condensing) |
