AXIS Q18 Series Q1809-LE / Network surveillance camera / bullet / outdoor / weather resistant / impact resistant / colour (Day&Night) / 41 MP / 7424 x 5568 / 8K / vari-focal / audio / GbE / H.265, MJPEG, H.264B, H.264H, H.264M, MPEG-4 Part 10 | 03019-001
Please sign in so that we can notify you about a reply
Product Features
- Robust environmental adaptability
Designed to withstand extreme temperatures ranging from -40°C to 55°C and humidity levels from 10 to 100% RH, ensuring reliable operation in challenging weather conditions. - Advanced optical performance
Features a vari-focal lens with a focal length range of 50 mm to 150 mm, automatic focus adjustment, and P-Iris control, delivering sharp, clear images across varying distances. - Comprehensive security standards
Meets a wide array of compliance standards including EAL 6+, IEC/EN 60529 IP67, and FIPS 140-3 Level 3, ensuring high security and durability in diverse operational environments. - High-capacity storage and connectivity
Supports up to 8 GB of flash memory and a variety of memory cards including microSD, microSDHC, and microSDXC, coupled with versatile connectivity options like RJ-45 LAN/power and 3.5 mm audio line-in/microphone. - Exceptional night vision capability
Equipped with infrared LEDs capable of illuminating up to 100 m, alongside features like Lightfinder 2.0 technology and OptimizedIR, it ensures high-quality surveillance in complete darkness.
Special Features
- High-resolution imaging with a total of 41,000,000 pixels for detailed surveillance footage
- Outdoor-ready with weather and impact resistance, suitable for harsh environments
- Versatile audio support including AAC-LC, G.711, and OPUS, enhancing video with high-quality sound
- Efficient power consumption at 17.6 watts, supporting DC, AC, and PoE class 6 power sources
- Flexible networking protocols including IPv6, HTTPS, and MQTT, ensuring seamless integration into existing systems
Product Specification
| Device Type | Network surveillance camera |
| Audio Support | Yes: 10-band graphic equaliser, microphone pairing, speaker pairing |
| Audio Formats | LPCM, AAC-LC, PCM, G.711, G.726, ADPCM, OPUS |
| Form Factor | Bullet |
| Connectivity Technology | Wired |
| Width | 18.3 cm |
| Depth | 41.1 cm |
| Height | 18.3 cm |
| Weight | 3.2 kg |
| Localisation | Argentina, Australia, Brazil, China, European Union, Japan, United Kingdom, United States |
| Camera | Camera |
| Type | Colour - Day&Night - fixed - outdoor - weather resistant / impact resistant |
| Digital Video Format | H.265, MJPEG, H.264B, H.264H, H.264M, MPEG-4 Part 10, AVC, MPEG-H Part 2, HEVC |
| Max Digital Video Resolution | 7424 x 5568 |
| Motion Detection | Yes |
| Video Modes | 8K |
| Exposure Range | 2 sec - 1/45500 sec |
| Minimum Illumination | 0.2 lux - colour - F4.0 - 50 IRE 0.04 lux - B&W - F4.0 - 50 IRE 0 lux - IR |
| Infrared LEDs | Yes |
| Infrared Distance | 100 m |
| Digital Video Capture Resolution | 7424 x 5568, 7680 x 4320, 7680 x 3240 |
| Frame Rate (max) | 30 frames per second |
| RAM | 8 GB |
| Flash Memory | 8 GB |
| Features | Lightfinder 2.0 technology, Electronic Image Stabilizer (EIS), Zipstream technology, secure boot, remote focus, remote zoom, infrared-cut filter, deep learning processing unit (DLPU), 21:9 aspect ratio, 16:9 aspect ratio, 4:3 aspect ratio, 20 video streams, Variable Bitrate (VBR), Adaptive Bitrate (ABR), Multi-Bitrate (MBR), low latency mode, video streaming indicator, Wide Dynamic Range (WDR), 2D digital noise reduction (DNR), 3D digital noise reduction (DNR), Automatic Gain Control (AGC), barrel distortion correction, brightness control, compression, contrast control, day/night threshold, Defog, digital PTZ function, dynamic text overlay, exposure mode, exposure zone, image mirror, image overlay, OptimizedIR, polygon privacy mask, Privacy Mask Function, saturation control, sharpness control, spectrum visualizer, text overlay, tone mapping, white balance, ONVIF (Profile G) support, ONVIF (Profile M) support, ONVIF (Profile S) support, ONVIF (Profile T) support, Pixel Counter Support, active tampering alarm, brute force delay protection, digest authentication, password protection, Network Time Security (NTS), 850nm illuminator, DORI coverage |
| Image Sensor | Image Sensor |
| Type | 41 MP PS RGB CMOS 4/3" |
| Lens Construction | Lens Construction |
| Type | Vari-focal |
| Optical Zoom | 3 x |
| Focal Length | 50 mm - 150 mm |
| Lens Iris | F/4.0 (P-Iris) |
| Focus Adjustment | Automatic |
| Min Focus Distance | 5 m |
| Horizontal Field of View (degree) | 6.6 - 21 |
| Vertical Field of View (degree) | 4 - 15 |
| Panning | Panning |
| Range (degree) | -180 to +180 |
| Tilting | Tilting |
| Range (degree) | 0 to -90 |
| Interfaces | Interfaces |
| Network Interface | Ethernet 10Base-T/100Base-TX/1000Base-T |
| Network Protocols | IPv4, IPv6, USGv6, ICMPv4, ICMPv6, HTTPS, HTTP, FTP, QOS, TLS, SFTP, SMB, CIFS, MDNS, Bonjour, SMTP, UPnP, SNMP, DNS, DDNS, DNSv6, NTP, NTS, SRTP, RTSP, RTP, TCP/IP, UDP/IP, IGMP, RTCP, DHCPv4, DHCPv6, ARP, SSH, LLDP, CDP, MQTT, Syslog, Zeroconf |
| Alarm Inputs Qty | 1 |
| Alarm Outputs Qty | 1 |
| Expansion / Connectivity | Expansion / Connectivity |
| Ports | LAN/power - RJ-45 Audio line-in/microphone - 3.5 mm jack |
| Supported Memory Cards | microSD Card, microSDHC Card, microSDXC Card |
| Encryption Algorithm | FIPS 140-3 Level 3, EAP-TLS, PEAP, MSCHAPv2, TLS 1.2, TLS 1.3 |
| Miscellaneous | Miscellaneous |
| Included Accessories | Terminal block connectors, owner authentication key, connector guard, cable gaskets |
| TAA Compliant | Yes |
| Compliant Standards | UL, cUL, EAC, VCCI, RCM, CISPR 35, CISPR 32 Class A, EN 55035, EN 55032 Class A, EN 50121-4, EN 61000-6-1, EN 61000-6-2, AS/NZS CISPR 32 Class A, ICES-3(A)/NMB-3(A), VCCI Class A, FCC Part 15 B Class A, IEC 62236-4, CAN/CSA C22.2 No. 62368-1 Third Edition, IEC/EN/UL 62368-1 Third Edition, IEC/EN 62471, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14, IEC 60068-2-27, IEC 60068-2-78, IEC/EN 60529 IP66, IEC/EN 60529 IP67, IEC/EN 62262 IK10, IK08, NEMA 250 Type 4X, NIST SP500-267, ETSI EN 303 645, EAL 6+, IEEE 802.1x, IEEE 802.1ae, IEEE 802.1ar, X.509, IEEE 802.3at, IEEE 802.3bt, PVC-free, BFR-free, CFR free, RoHS 2011/65/EU, EN 63000:2018, REACH 2006/1907 |
| Colour | White, NCS S 1002-B, NCS S 9000-N, black |
| Power | Power |
| Power Requirements | DC 10 - 28 V / AC 20 - 24 V / PoE class 6 |
| Power Device | 17.6 Watt |
| Software / System Requirements | Software / System Requirements |
| Software Included | AXIS Video Motion Detection |
| Manufacturer Warranty | Manufacturer Warranty |
| Service & Support | Limited warranty - 5 years |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | -40 °C |
| Max Operating Temperature | 55 °C |
| Relative Humidity (operating) | 10 - 100% RH (condensing) |
Features - AXIS - 03019-001
More Details
Product Code
CL06401
EAN Code
7331021087910
Manufacturer
AXIS
