PLANET GT-805A - Fibre media converter - GigE - 10Base-T, 1000Base-LX, 1000Base-SX, 100Base-TX, 1000Base-T - RJ-45 / SFP (mini-GBIC) | GT-805A
Please sign in so that we can notify you about a reply
Special Fetures
- Complies with IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX, IEEE 802.3ab 1000Base-T, IEEE 802.3z 1000Base-SX/LX
- TP port supports 10/100/1000Base-T auto-negotiation and auto-MDI/MDI-X
- Auto-negotiation for 10/100/1000Base-T; half-duplex or full-duplex for 10Mbps and 100Mbps
- Media conversion between 10/100/1000Base-T and 1000Base-SX/LX
- Wall-mountable design
- LED indicators for easy network diagnose
- Choice of fiber-connector from SC, LC and WDM, multi-mode/single-mode fiber for 1000Base SFP interface
- 9K jumbo frame supported
- OAM (TS-1000 and IEEE 802.3ah) supported
Product Specification
| Device Type | Fibre media converter |
| Form Factor | External |
| Networking | |
| Connectivity Technology | Wired |
| Cabling Type | 10Base-T, 1000Base-LX, 1000Base-SX, 100Base-TX, 1000Base-T |
| Data Link Protocol | 10Mb LAN, 100Mb LAN, GigE |
| Data Transfer Rate | 1 Gbps |
| Status Indicators | Power, link/activity |
| Features | Auto-negotiation, auto-uplink (auto MDI/MDI-X), half duplex mode, full duplex mode |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.3ab, IEEE 802.3ah |
| Expansion / Connectivity | |
| Expansion Slots | 1 SFP (mini-GBIC) |
| Interfaces | 1 x Ethernet 10Base-T/100Base-TX/1000Base-T - RJ-45 |
| Miscellaneous | |
| Compliant Standards | FCC Class A certified |
| Power | |
| Power Consumption Operational | 5.6 Watt |
| Dimensions & Weight | |
| Width | 9.7 cm |
| Depth | 6.9 cm |
| Height | 2.6 cm |
| Environmental Parameters | |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 50 °C |
| Humidity Range Operating | 5 - 90% |
Features - Planet - GT-805A
More Details
Product Code
04:247702
EAN Code
4711213686887
Manufacturer
Planet
