PLANET MGB-GT / SFP (mini-GBIC) transceiver module / 1GbE / 1000Base-T / SFP (mini-GBIC) / RJ-45 / up to 100 m | MGB-GT
Please sign in so that we can notify you about a reply
Special Features
- Comply with the IEEE 802.3ab/802.3z Gigabit Ethernet standard
- Duplex LC connector
- Differential PECL inputs and outputs
- Single power supply
- TTL signal detect indicator
- Hot pluggable
- Plug and Play installation
Product Specification
| Device Type | SFP (mini-GBIC) transceiver module |
| Form Factor | Plug-in module |
| Networking | Networking |
| Connectivity Technology | Wired |
| Cabling Type | 1000Base-T |
| Data Link Protocol | 1GbE |
| Data Transfer Rate | 1 Gbps |
| Max Transfer Distance | 100 m |
| Features | Auto-negotiation, auto-uplink (auto MDI/MDI-X) |
| Compliant Standards | IEEE 802.3ab |
| Expansion / Connectivity | Expansion / Connectivity |
| Interfaces | 1 x Ethernet 1000Base-T - RJ-45 |
| Compatible Slots | 1 x SFP (mini-GBIC) |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 50 °C |
Features - Planet - MGB-GT
More Details
Product Code
04:199643
EAN Code
4711213687600
Manufacturer
Planet
