QNAP QSW-M3212R-8S4T - Switch - Managed - 4 x 100/1000/2.5G/5G/10GBase-T + 8 x 10Gb Ethernet SFP+ - rack-mountable | QSW-M3212R-8S4T
Please sign in so that we can notify you about a reply
Product Specification
| Device Type | Switch - 12 ports - Managed |
| Enclosure Type | Rack-mountable |
| Subtype | 10 Gigabit Ethernet |
| Ports | 4 x 100/1000/2.5G/5G/10GBase-T + 8 x 10Gb Ethernet SFP+ |
| Performance | Switching capacity: 240 Gbps ¦ Non-blocking switching throughput: 120 Gbps |
| MAC Address Table Size | 16K entries |
| Jumbo Frame Support | 9KB |
| Features | Layer 2 switching, VLAN support, IGMP snooping, Rapid Spanning Tree Protocol (RSTP) support, Access Control List (ACL) support, Quality of Service (QoS), reset button, LACP support, LLDP support, DHCP client, Type of Service (ToS), 2 fans, DNS client, port-based QoS, SNTP client, web-based management, DSCP based QoS |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.3ae, IEEE 802.1ab (LLDP) |
| Status Indicators | Power, status, link/activity/speed |
| Expansion / Connectivity | |
| Interfaces | 8 x 10Gbit LAN SFP+ ¦ 4 x 10Gbit LAN RJ-45 ¦ 1 x management (Gigabit LAN) RJ-45 ¦ 1 x console RJ-45 |
| Power | |
| Power Device | Internal power supply |
| Voltage Required | AC 100-240 V (50/60 Hz) |
| Miscellaneous | |
| Included Accessories | Power cord |
| Rack Mounting Kit | Included |
| Compliant Standards | VCCI, BSMI, FCC, Class A |
| Dimensions & Weight | |
| Width | 20.7 cm |
| Depth | 19.95 cm |
| Height | 4.33 cm |
| Weight | 1.48 kg |
| Dimensions & Weight (Shipping) | |
| Shipping Weight | 2.19 kg |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 2 years |
| Environmental Parameters | |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 40 °C |
| Humidity Range Operating | 5 - 95% (non-condensing) |
Features - QNAP - QSW-M3212R-8S4T
General
8-Port
More Details
Product Code
04:457301
EAN Code
4711103084328
Manufacturer
QNAP
