QNAP QXP-10G2U3A / USB adapter / PCIe 2.0 x2 low profile / USB 3.2 Gen 2 x 2 / for QNAP TS-1232, 1253, 1277, 253, 453, 473, 677, 853, 877, 977, TVS-2472, 473, 673, 872, 873 | QXP-10G2U3A
Please sign in so that we can notify you about a reply
Product Features
- Experience USB 3.2 Gen 2 SuperSpeed+ up to 10Gbps
The QNAP USB 3.2 Gen 2 Expansion Card provides speeds of up to 10Gbps - double that of USB 3.2 Gen 1, and 20 times that of USB 2.0. - Expand your storage by connecting to a QNAP USB JBOD
By using a QNAP USB 3.2 Gen 2 Expansion Card in your QNAP NAS or PC, you can connect a QNAP USB JBOD to back up and expand your storage. The USB 3.2 Gen 2 Expansion Card supports both QNAP NAS and Windows /Ubuntu PCs without requiring drivers. You can configure RAID and monitor disk health using the QTS/QuTS hero Storage & Snapshots Manager on a QNAP NAS, or by using the QNAP JBOD Manager utility on your computer.
Special Features
- Dual-port USB 3.2 Gen 2 Type-A connectivity
- Supports USB Attached SCSI Protocol (UASP) to provide convenient fast file sharing and intensive data transfer
- Uses advanced low-power processes, following standard PCIe/USB bus Power Management to reduce power consumption
- Supports overcurrent detection and short circuit protection
- Supports Windows 8.x / 10 (32/64-bit) and Ubuntu desktop 20.04 LTS. No driver is required
Product Specification
| Device Type | USB adapter |
| Form Factor | Plug-in card - low profile |
| Interface (Bus) Type | PCI Express 2.0 x2 |
| Networking | Networking |
| Ports | USB 3.2 Gen 2 x 2 |
| Data Link Protocol | USB 3.2 Gen 2 |
| Data Transfer Rate | 10 Gbps |
| Features | Over-current protection, short circuit protection |
| Compliant Standards | USB 3.2 Gen 2 |
| Processor / Memory | Processor / Memory |
| Processor | 1 x ASMedia ASM3142 |
| Expansion / Connectivity | Expansion / Connectivity |
| Interfaces | 2 x USB 3.2 Gen 2 - 9 pin USB Type A |
| Miscellaneous | Miscellaneous |
| Included Accessories | Low-profile bracket, full-height bracket |
| Software / System Requirements | Software / System Requirements |
| OS Required | Windows 8 / 8.1 / 10 (32/64 bits), QNAP QTS 4.3.6 or later, Ubuntu 20.04 LTS |
| Dimensions & Weight | Dimensions & Weight |
| Width | 1.4 cm |
| Depth | 8.965 cm |
| Height | 6.89 cm |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 40 °C |
| Humidity Range Operating | 5 - 95% (non-condensing) |
| Compatibility Information | Compatibility Information |
| Designed For | QNAP SS-EC1279U-SAS-RP, SS-EC1879U-SAS-RP, SS-EC2479U-SAS-RP, TS-1079 Pro, TS-1232XU, TS-1232XU-RP, TS-1253BU-RP, TS-1263U-RP, TS-1270U-RP Turbo NAS, TS-1273U-RP, TS-1277, TS-1279U-RP Turbo NAS, TS-1679U-RP Turbo NAS, TS-253B, TS-253Be, TS-453Be, TS-453BT3, TS-463U, TS-463U-RP, TS-470 Pro Turbo NAS, TS-470 Turbo NAS, TS-473, TS-563 Turbo NAS, TS-653B, TS-670 Turbo NAS, TS-677, TS-853BU, TS-853DU-RP, TS-863U, TS-863U-RP, TS-870 Turbo NAS, TS-870U-RP Turbo NAS, TS-873U, TS-877, TS-877XU-RP, TS-879Pro, TS-879U-RP Turbo NAS, TS-977XU-RP, TS-EC1080 Pro Turbo NAS, TS-EC1279U-RP Turbo NAS, TS-EC1279U-SAS-RP Turbo NAS, TS-EC1280U, TS-EC1280U-RP Turbo NAS, TS-EC1679U-RP, TS-EC1679U-SAS-RP, TS-EC879U-RP Turbo NAS, TS-EC880 Pro Turbo NAS, TVS-2472XU-RP, TVS-463 Turbo NAS, TVS-471, TVS-473e, TVS-663 Turbo NAS, TVS-671, TVS-673e, TVS-682T, TVS-863 Turbo NAS, TVS-863+ Turbo NAS, TVS-871, TVS-871U-RP, TVS-872XU, TVS-873e, TVS-882BRT3, TVS-882ST2, TVS-EC1080+ Turbo NAS, TVS-EC1280U-SAS-RP, TVS-EC1580MU-SAS-RP, TVS-EC2480U-SAS-RP, TVS-EC880 Turbo NAS |
Features - QNAP - QXP-10G2U3A
More Details
Product Code
04:385296
EAN Code
4713213518113
Manufacturer
QNAP
