Samsung 990 EVO MZ-V9E2T0BW / SSD / encrypted / 2 TB / internal / M.2 2280 / PCI Express 5.0 x4 (NVMe) / 256-bit AES / TCG Opal Encryption 2.0 | MZ-V9E2T0BW
Product Features
- Enhanced durability
Equipped with Dynamic Thermal Guard protection, the Samsung 990 EVO ensures optimal performance by preventing overheating, making it a reliable choice for intensive tasks. - High-speed performance
With an internal data rate of up to 5000 MBps for reading and 4200 MBps for writing, alongside PCI Express 5.0 x4 (NVMe) interface, this solid state drive offers swift data transfer speeds, enhancing your computing experience. - Robust security
Featuring 256-bit AES hardware encryption and TCG Opal Encryption 2.0, the Samsung 990 EVO provides advanced data security, protecting your sensitive information against unauthorized access. - Efficient operation
The Auto Garbage Collection Algorithm and Device Sleep support contribute to efficient power management, reducing energy consumption while maintaining high performance. - Exceptional capacity
With a 2 TB capacity and equipped with a 2GB LPDDR4 DRAM cache, this hard drive offers ample storage space and improved data retrieval speeds, making it ideal for heavy-duty applications.
Special Features
- 2 TB capacity for extensive storage needs
- PCI Express 5.0 x4 (NVMe) interface for swift data transfer
- Dynamic Thermal Guard protection for durability
- 256-bit AES hardware encryption for secure data protection
- 5000 MBps read and 4200 MBps write speeds for efficient performance
Product Specification
Device Type | Solid state drive - internal |
Capacity | 2 TB |
Hardware Encryption | Yes |
Encryption Algorithm | 256-bit AES |
NAND Flash Memory Type | Triple-level cell (TLC) |
Form Factor | M.2 2280 |
Interface | PCI Express 5.0 x4 (NVMe) |
Features | TRIM support, Auto Garbage Collection Algorithm, Device Sleep support, Samsung V-NAND TLC Technology, 2GB LPDDR4 DRAM cache, Dynamic Thermal Guard protection, S.M.A.R.T. |
Width | 22 mm |
Depth | 80 mm |
Height | 2.38 mm |
Weight | 9 g |
Performance | Performance |
Internal Data Rate | 5000 MBps (read) / 4200 MBps (write) |
4KB Random Read | 22000 IOPS |
4KB Random Write | 90000 IOPS |
Maximum 4KB Random Write | 800000 IOPS |
Maximum 4KB Random Read | 700000 IOPS |
Expansion & Connectivity | Expansion & Connectivity |
Compatible Bay | M.2 2280 |
Power | Power |
Power Consumption | 5.4 Watt (read) 4.7 Watt (write) |
Software & System Requirements | Software & System Requirements |
Software Included | Samsung Magician Software |
Miscellaneous | Miscellaneous |
Compliant Standards | IEEE 1667 |
Package Details | Box |
Manufacturer Warranty | Manufacturer Warranty |
Service & Support | Limited warranty - 5 years |
Environmental Parameters | Environmental Parameters |
Min Operating Temperature | 0 °C |
Max Operating Temperature | 70 °C |
Shock Tolerance (non-operating) | 1500 g @ 0.5 ms |
