Sapphire Pulse Radeon RX 580 / Graphics card / Radeon RX 580 / 8 GB GDDR5 / PCIe 3.0 x16 / DVI, 2 x HDMI, 2 x DisplayPort / lite retail | 11265-05-20G
11265-05-20G
Find similar
Delivery
Payment options
Please sign in so that we can notify you about a reply
Sapphire Pulse Radeon RX 580 / Graphics card / Radeon RX 580 / 8 GB GDDR5 / PCIe 3.0 x16 / DVI, 2 x HDMI, 2 x DisplayPort / lite retail | 11265-05-20G
Description
SAPPHIRE Pulse is all about providing PC users with choice and great value for money. Starting with the SAPPHIRE Pulse Radeon RX 580, this factory-overclocked model is dedicated to customers who seek a powerful, future-proof card that plays modern titles at maximum fidelity. The industry proven SAPPHIRE Dual-X system serves as the cooling solution, with dual ball-bearing fans and the SAPPHIRE Quick Connect feature for easy cleaning and replacement.
Sapphire Pulse Radeon RX 580 / Graphics card | 11265-05-20G
Special Features
- Fuse protection
- Black Diamond Choke 4
- Dual-X cooling
- No stuttering, no tearing, just gaming
- AMD XConnect technology
Product features
- Fuse protection
In order to protect your card, the SAPPHIRE cards have fuse protection built into the circuit of the external PCI-E power connector to keep the components safe. - Black Diamond Choke 4
Black Diamond Chokes are cooler and more power efficient than a normal choke - and these chokes reduce the coil temperatures. These exclusive chokes will maintain gaming stability using their built-in heatsinks and help minimize coil whine. - Dual-X cooling
SAPPHIRE's Dual-X cooling is powered by two massive yet silent fans and state-of-the-art radiator design. The form of blades means greater airflow and superior heatsink coverage at lower noise compared to standard cooling designs. - No stuttering, no tearing, just gaming
AMD FreeSync technology allows a compatible graphics card and monitor to dynamically change frame rates for the optimum display quality without tearing or stuay. - AMD XConnect technology
Now it's easier than ever to connect and use an external graphics card. With AMD XConnect technology, external GPU enclosures configured with Radeon graphics can easily connect and disconnect to a compatible ultrathin notebook or 2-in 1 over Thunderbolt 3 at any time, just like a USB flash drive!
Product Specification
| Device Type | Graphics card |
| Bus Type | PCI Express 3.0 x16 |
| Graphics Engine | AMD Radeon RX 580 |
| Core Clock | 1366 MHz |
| Stream Processors | 2304 |
| Process Technology | 14 nm |
| Max Resolution | 3840 x 2160 |
| Max Resolution Details | DVI: 2560 x 1600 / DisplayPort: 3840 x 2160 / HDMI: 3840 x 2160 |
| Max Monitors Supported | 5 |
| Interfaces | 2 x HDMI ¦ 2 x DisplayPort ¦ DVI-D |
| API Supported | DirectX 12, OpenGL 4.5, OpenCL 2.0 |
| Features | Sapphire Black Diamond Choke, High dynamic-range (HDR) rendering, AMD Eyefinity Technology, AMD CrossFireX Technology, Shader Model 5.0, Dual-X cooler, Graphics Core Next (GCN), Dual ball Bearing Fan, UEFI BIOS, factory overclocked, FreeSync Technology, AMD LiquidVR Technology, Frame Rate Target Control(FRTC), AMD XConnect Technology, NITRO Quick Connect system, Intelligent Fan Control (IFC) III, Black Diamond Chokes 4, Sapphire Dual-X Cooling Technology, fuse protection |
| Size | 8 GB |
| Technology | GDDR5 SDRAM |
| Effective Clock Speed | 7 GHz |
| Bus Width | 256-bit |
| OS Required | Microsoft Windows 7 / 10 |
| Required Power Supply | 500 W |
| Additional Requirements | CD-ROM, 8 pin PCI Express power connector |
| Power Consumption Operational | 225 Watt |
| Width | 4 cm |
| Depth | 23 cm |
| Height | 12.5 cm |
| Package Type | Lite retail |
