Seagate Exos X22 ST20000NM004E - Hard drive - 20 TB - internal - 3.5" - SAS 6Gb/s - 7200 rpm | ST20000NM004E
ST20000NM004E
Form Factor3.5"
Capacity20TB
InterfaceSAS
Product Code07:349472
EAN Code8719706428361
ManufacturerSeagate
Find similar
Delivery
Payment options
Please sign in so that we can notify you about a reply
Product Features
- Enhanced durability
The Seagate Exos X22 is engineered with a helium sealed-drive design and Super Parity, ensuring reliable data integrity and drive longevity, even in continuous operation environments. - Optimized power management
Featuring Power Choice Idle Power technology and PowerBalance power/performance technology, this hard drive optimizes power consumption without sacrificing performance, making it an eco-friendly choice for data centers. - High capacity storage
With a massive 20 TB capacity, the Seagate Exos X22 meets the growing demands for data storage, supporting extensive data analysis and secure archiving. - Efficient data transfer
Boasting a data transfer rate of 600 MB/s and an internal data rate of 285 MB/s, this hard drive ensures swift and reliable data access, enhancing overall system performance.
Special Fetures
- 20 TB capacity for extensive storage needs
- 600 MB/s data transfer rate for efficient operations
- 24x7 availability with helium sealed-drive design for enhanced reliability
- Power Choice Idle Power technology for eco-friendly power management
- 2,500,000 hours MTBF for long-term dependability
Product Specification
| Device Type | Hard drive - internal |
| Capacity | 20 TB |
| Form Factor | 3.5" |
| Interface | SAS 6Gb/s |
| Features | Helium Sealed-Drive Design, Conventional magnetic recording (CMR), Super Parity, Low Halogen, Power Choice Idle Power technology, PowerBalance power/performance technology, Hot-Plug Support, Organic Solderability Preservative, 24x7 availability, single port |
| Width | 101.85 mm |
| Depth | 147 mm |
| Height | 26.1 mm |
| Weight | 680 g |
| Performance | |
| Drive Transfer Rate | 600 MBps (external) |
| Internal Data Rate | 285 MBps |
| Average Latency | 4.16 ms |
| Spindle Speed | 7200 rpm |
| Reliability | |
| MTBF | 25,000,00 hours |
| 24x7 Operation | Yes |
| Non-Recoverable Errors | 1 per 10^15 |
| Expansion & Connectivity | |
| Interfaces | 1 x SAS 6Gb/s |
| Compatible Bay | 3.5" |
| Power | |
| Voltage Required | 5 - 12 V |
| Power Consumption | 5.4 Watt (average idle) <br /> 9.4 Watt (max read) <br /> 6.4 Watt (max write) |
| Miscellaneous | |
| Compliant Standards | RSA 3072 Firmware |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 5 years |
| Environmental Parameters | |
| Min Operating Temperature | 10 ?C |
| Max Operating Temperature | 60 ?C |
| Shock Tolerance (operating) | 40 g |
| Shock Tolerance (non-operating) | 200 g |
| Vibration Tolerance (operating) | 20-1500 Hz |
| Vibration Tolerance (non-operating) | 2.27 g |
Features - Seagate - ST20000NM004E
Form Factor
- 3.5"
Capacity
20TB
Interface
- SAS
More Details
Product Code
07:349472
EAN Code
8719706428361
Manufacturer
Seagate
