Sharkoon WPM Gold ZERO 550 / Power supply (internal) / ATX12V 2.3 / 80 PLUS Gold / AC 100-240 V / 550 Watt / active PFC / black | 4044951026548
Description
The WPM Gold ZERO is a reliable power supply with modern LLC resonant converter technology. The power supply delivers optimal performance for gaming PCs and is energy efficient.
Sharkoon WPM Gold ZERO 550 / Power supply (internal) | 4044951026548
Special Features
- Modern LLC technology
- Silent operation
Product features
- Modern LLC technology
The WPM Gold ZERO is equipped with LLC resonant converter technology. This provides the power supply with a consistent and low-interference voltage. Noise and heat levels are minimized as far as possible. - Silent operation
The zero RPM function disables the fan rotation of the power supply to provide a silent operation at low to medium loads. When the system again requires an active cooling, the fan rotation is automatically reactivated.
Product Specification
| Device Type | Power supply - active Power Factor Correction (PFC) - internal |
| Specification Compliance | ATX12V 2.3 |
| PSU Form Factor | ATX |
| Colour | Black |
| Input Voltage | AC 100-240 V |
| Frequency Required | 47 - 63 Hz |
| Power Output Connectors Details | 1 x power 24 pin ATX ¦ 1 x power 8 pin +12V with detachable 4 pin section ¦ 4 x 8 pin PCI Express power with detachable 2 pin section ¦ 9 x 15 pin Serial ATA power ¦ 3 x 4 PIN internal power ¦ 1 x 4 PIN mini-power connector |
| Output Voltage | +3.3, +5, ±12 V |
| Power Capacity | 550 Watt |
| Output Current | +3.3V - 20 A ¦ +5V - 20 A ¦ +12V - 45 A ¦ +5VSB - 2.5 A ¦ -12V - 0.3 A |
| Efficiency | 87% at 20% Load, 90% at 50% Load, 87% at 100% Load |
| Modular Cable Management | Yes |
| 80 PLUS Certification | 80 PLUS Gold |
| Included Accessories | Screws, cable bag |
| Cables Included | Power cable - external |
| MTBF | 100,000 hours |
| Cooling System | 140 mm fan |
| Features | Over voltage protection, overpower protection, short-circuit protection, single 12V rail, DC-DC technology, sleeve bearing cooling fan, semi-modular, LLC resonant converter technology |
| Compliant Standards | CB, FCC, ERP, Directive 2012/19/EU |
| Service & Support | Limited warranty - 2 years |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 40 °C |
| Width | 15 cm |
| Depth | 16 cm |
| Height | 8.6 cm |
| Weight | 1.61 kg |
Features - Sharkoon - 4044951026548
More Details
Product Code
04:334836
EAN Code
4044951026548
Manufacturer
Sharkoon
