Product Features
- Stylish and absolutely small
The black plastic case with its curves is certain to be the eye catcher on your desk. It may also be elegantly hidden behind monitors thanks to the supplied VESA mount. Despite its dinky dimensions, it provides generous connectivity options and even room for one 2.5 inch drive. - Seven USB 3.2 ports
Up to 7 USB devices can be connected to the NC40U. The USB-C port can also be used as a DisplayPort. The red USB ports even support USB 3.2 Gen2 with up to 10 Gbit/s. - Supports two M.2 SSD cards and one 2.5" drive
This nano PC has room for two SSD cards in M.2-2280 format with fast PCIe interface and NVMe support (one card with SATA is supported). Two self-adhesive thermal pads are included. NC40U also supports RAID 0/1 configuration for two M.2 PCIe SSDs thanks to the Intel Volume Management Device Technology (Intel VMD). - Power On after Power fail
The BIOS setup provides a "Power-On after Power Fail" function that can be found under "Power Management Configuration". As the name indicates, this function determines the PC's behavior after power failure: (1) unconditional power on, (2) restore former status, (3) keep system turned off, (4) Power-On by LAN or (5) Power-On by Real-Time-Clock. As a matter of the nature of this function, it may fail after short power failures. This is why the Shuttle XPC slim Barebone NC40U also comes with a hardware-based solution. By removing Jumper JP1 the system will start unconditionally once power is applied. - Triple 4K display support
The NC40U features three digital video outputs: HDMI, DisplayPort and USB-C. This allows for the connection of three independent 4K displays which all can run with 3 840 x 2 160 Ultra HD resolution at 60 Hz frames per second.
Special Fetures
- Stylish and absolutely small
- Seven USB 3.2 ports
- Supports two M.2 SSD cards and one 2.5" drive
- Power On after Power fail
- Triple 4K display support
Product Specification
| Type | PC barebone |
| Product Form Factor | Mini PC |
| Embedded Security | Firmware Trusted Platform Module (TPM 2.0) Security Chip |
| Colour | Black |
| Processor / Chipset | |
| CPU | Intel Celeron 7305 |
| Clock Speed | 1.1 GHz |
| Number of Cores | 5-core |
| CPU Qty | 1 |
| Max CPU Qty | 1 |
| Cache Memory | |
| Installed Size | 8 MB |
| Cache Per Processor | 8 MB |
| RAM | |
| Installed Size | 0 GB / 64 GB (max) |
| Technology | DDR4 SDRAM - non-ECC |
| Form Factor | SO-DIMM 260-pin |
| Slots | 2 (Total) / 2 (empty) |
| Features | Unbuffered, dual channel memory architecture |
| Hard Drive | |
| Type | No HDD |
| Storage Controller | |
| Type | 1 x SATA |
| Controller Interface Type | SATA 6Gb/s |
| Channel Qty | 1 |
| Optical Storage | |
| Type | No optical drive |
| Monitor | |
| Monitor Type | None. |
| Graphics Controller | |
| Graphics Processor | Intel UHD Graphics 620 |
| Video Interfaces | HDMI, DisplayPort |
| Audio Output | |
| Compliant Standards | High Definition Audio |
| Networking | |
| Ethernet Controller | Intel I219 |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Expansion / Connectivity | |
| Bays | 1 (total) / 1 (free) x internal 2.5" x 1/8H |
| Slots | 2 (total) / 2 (free) x M.2 Card - 2280 |
| Interfaces | 6 x USB 3.2 Gen 2 ¦ 1 x USB-C 3.1 Gen 2 ¦ 1 x HDMI ¦ 1 x LAN (Gigabit Ethernet) ¦ 1 x DisplayPort ¦ 1 x audio line-out/headphones ¦ USB 3.1 Gen 2 ¦ 1 x microphone |
| Miscellaneous | |
| Included Accessories | Horizontal feet, VESA mounting kit |
| Theft/Intrusion Protection | Security lock slot (cable lock sold separately) |
| Security Slot Type | Kensington security slot |
| VESA Mounting Interface | 100 x 100 mm, 75 x 75 mm |
| Power | |
| Device Type | Power adapter |
| Voltage Required | AC 100-240 V (50/60 Hz) |
| Power Provided | 65 Watt |
| Operating System / Software | |
| OS Provided | No operating system |
| Dimensions & Weight | |
| Width | 14.2 cm |
| Depth | 14.2 cm |
| Height | 4.2 cm |
| Weight | 400 g |
| Dimensions & Weight (Shipping) | |
| Shipping Weight | 1.2 kg |
