Shuttle XPC nano NC40U3 - Barebone - mini PC - 1 x Core i3 1215U - RAM 0 GB - UHD Graphics 620 - Gigabit Ethernet - black | NC40U3
Please sign in so that we can notify you about a reply
Product Features
- Three expansion options via M.2 module
Three M.2 slots enable expansion with several data carriers and additional modules, for example for WLAN or mobile radio. Thanks to the fast PCI Express connection, high data volumes can be transported in a short time via the M.2 slot. - Three 4K-capable monitor connections
Various graphics outputs with ultra-high resolution digital signals, offer flexibility in the choice of displays and enable multi-monitoring. This model has one HDMI, one DisplayPort and one USB-C port that can be used simultaneously. - Space for a 2.5" drive
As a complement to an NVMe SSD, this model also offers a home to classic data storage devices in 2.5" format. Hard disks and SSDs in this format offer many terabytes of storage space.
Special Fetures
- Intel Core processor
- Intel UHD Graphics for 12th Gen Intel processor
- DDR4 SO-DIMM memory
- Always-on jumper
- Wall/VESA mount included
Product Specification
| Type | PC barebone |
| Product Form Factor | Mini PC |
| Embedded Security | Firmware Trusted Platform Module (TPM 2.0) Security Chip |
| Colour | Black |
| Processor / Chipset | |
| CPU | Intel Core i3 (12th Gen) 1215U |
| Max Turbo Speed | 4.4 GHz (P-core) / 3.3 GHz (E-core) |
| Number of Cores | 6-core |
| CPU Qty | 1 |
| Max CPU Qty | 1 |
| Processor Main Features | Intel Smart Cache |
| Cache Memory | |
| Installed Size | L3 Cache - 10 MB |
| Cache Per Processor | 10 MB |
| RAM | |
| Installed Size | 0 GB / 64 GB (max) |
| Technology | DDR4 SDRAM - non-ECC |
| Form Factor | SO-DIMM 260-pin |
| Slots | 2 (Total) / 2 (empty) |
| Features | Unbuffered, dual channel memory architecture |
| Hard Drive | |
| Type | No HDD |
| Storage Controller | |
| Type | 1 x SATA |
| Controller Interface Type | SATA 6Gb/s |
| Channel Qty | 1 |
| Optical Storage | |
| Type | No optical drive |
| Monitor | |
| Monitor Type | None. |
| Graphics Controller | |
| Graphics Processor | Intel UHD Graphics 620 |
| Video Interfaces | HDMI, DisplayPort |
| Audio Output | |
| Compliant Standards | High Definition Audio |
| Networking | |
| Ethernet Controller | Intel I219 |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Expansion / Connectivity | |
| Bays | 1 (total) / 1 (free) x internal 2.5" x 1/8H |
| Slots | 2 (total) / 2 (free) x M.2 Card - 2280 |
| Interfaces | 6 x USB 3.2 Gen 2 ¦ 1 x USB-C 3.1 Gen 2 ¦ 1 x HDMI ¦ 1 x LAN (Gigabit Ethernet) ¦ 1 x DisplayPort ¦ 1 x audio line-out/headphones ¦ USB 3.1 Gen 2 ¦ 1 x microphone |
| Miscellaneous | |
| Included Accessories | Horizontal feet, VESA mounting kit |
| Theft/Intrusion Protection | Security lock slot (cable lock sold separately) |
| Security Slot Type | Kensington security slot |
| VESA Mounting Interface | 100 x 100 mm, 75 x 75 mm |
| Power | |
| Device Type | Power adapter |
| Voltage Required | AC 100-240 V (50/60 Hz) |
| Power Provided | 65 Watt |
| Operating System / Software | |
| OS Provided | No operating system |
| Dimensions & Weight | |
| Width | 14.2 cm |
| Depth | 14.2 cm |
| Height | 4.2 cm |
| Weight | 400 g |
| Dimensions & Weight (Shipping) | |
| Shipping Weight | 1.2 kg |
Features - Shuttle - NC40U3
CPU Type
- Intel Core i3
More Details
Product Code
CI66533
EAN Code
0887993005898
Manufacturer
Shuttle
